AL191 - HOLI Scale's AL191 Single Point Load Cell

Experience the zenith of precision weighing with HOLI Scale's AL191 load cell. Showcasing a commanding 1000kg capacity and crafted from superior aluminium, the AL191 sets the gold standard for high-capacity industrial weighing. Elevate your weighing needs with the unmatched AL191.
  • AL191

  • HOLI

  • CE, OIML, NTEP, RoHS

Availability:
Quantity:


Product Description:


Capacity: 50kg to 1000kg

The AL191 load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. Experience the zenith of precision weighing with HOLI Scale's AL191 load cell. Showcasing a commanding 1000kg capacity and crafted from super or aluminium, the AL191 sets the gold standard for high-capacity industrial weighing. Elevate your weighing needs with the unmatched AL191.


Model Products Description
AL 191-50kg OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.
AL 191-100kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-150kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-200kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-250kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-300kg OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.
AL 191-500kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-635kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-750kg

OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.

AL 191-1000kg OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores.
AL 191-660lb NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores.
AL 191-1400lb NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores.


Product dimensions(mm):

AL191

Aluminium Single-Point Load Cell AL191

Parameter Specifications Units
Rated capacity (Emax) 50/ 100/ 150/ 200/ 250/ 300/ 500/ 635/ 750/ 1000 kg
660/ 1400 lb
Accuracy class C3 C3MR C5 C6
Maximum number of LC intervals (Nmax) 3000 2*3000 5000 6000
Min. LC verification interval (Vmin) Emax / 5000 Emax / 10000 g
Zero balance ±0.1 mV/V
Min.dead load
0
kg
Rated output 2.0 mV/V
Rated output tolerance ± 0.2 mV/V
Pepeatability ± 0.010 ± 0.010 ± 0.006 ± 0.005 % of AL*
Creep 30 minute
± 0.017 ± 0.017 ± 0.0010 ± 0.0083 % of AL
Temp. effect on rated output  +20...+40℃ ± 0.00175 ± 0.00175 ± 0.00105 ± 0.00087 % of Emax/℃
                                                              -10...+20℃ ± 0.00117 ± 0.00117 ± 0.0007 ± 0.00058 % of AL/℃
Temp. effect on zero balance ± 0.0028 ± 0.0014 % of Emax/℃
Hysteresis error ± 0.0175 ± 0.0175 ± 0.0105 ± 0.0105 % of Emax
Non-linearity error ± 0.0175 ± 0.0175 ± 0.0105 ± 0.0105 % of Emax
Min. dead load output return ± 0.0166 ± 0.0166 ± 0.0100 ± 0.0083 % of AL
Offer center load error (OIML R76)
± 0.0044 ± 0.0044 ± 0.0026 ± 0.0022 % of AL/cm
Input resistance 404± 15 Ω
Output resistance 350 ± 3 Ω
Insulation resistance @50VDC >5000
Excitation voltage Recommended 10 V AC/DC
Maximum 15 V AC/DC
Temperature range Compensated -10 to +40
Operating -10 to +50
Safe storage -25 to +70
Load limit Safe 150 % of Emax
Ultimate 300 % of Emax
Protection Type

Silicone rubber over gage


IP rating IP65
OIML / European Approval OIML Cert. No. R60/2017-A-NL1-21.23

European Cert. No. TC11565

Class C6
nmax 6000
NTEP Approval Cert. No. 23-026
Class
nmax 6000
Cable Length 2.5 m
Type 4 or 6 cores, PVC
Construction Aluminium
Maximum platform size 600×800 mm
Recommended torque

50kg to 300kg: 25.0/ above 300kg: 30.0

N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60.

*AL: Applied load.
