AL188
HOLI
CE, OIML, NTEP, RoHS
| Quantity: | |
|---|---|
Capacity: 50kg to 1000kg
The AL188 load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. In the bustling realm of industrial weighing, there stands a product that encapsulates the perfect blend of design and efficiency: the AL188 load cell by HOLI Scale. Distinguished for its impeccable precision, and tailored to meet the demands of a dynamic industry, the AL188 offers an unrivaled experience.
| Model | Products Description |
| AL 188-50kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-100kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
AL 188-150kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-200kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-250kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-300kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-500kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-750kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-1000kg | OIML, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-165lb | NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-220lb | NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-330lb | NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-440lb | NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-660lb | NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
| AL 188-1100lb | NTEP, aluminium alloy steel, 2.5m wire with 4 or 6 cores. |
Aluminium Single-Point Load Cell AL188 | |||||||
| Parameter | Specifications | Units | |||||
| Rated capacity (Emax) | 50/ 100/ 150/ 200/ 250/ 300/ 500/ 750/ 1000 | kg | |||||
| 165/ 220/ 330/ 440/ 660/ 1100 | lb | ||||||
| Accuracy class | C3 | C3MR | C5 | C6 | |||
| Maximum number of LC intervals (Nmax) | 3000 | 2*3000 | 5000 | 6000 | |||
| Min. LC verification interval (Vmin) | Emax / 5000 | Emax / 10000 | g | ||||
| Zero balance | ±0.1 | mV/V | |||||
| Min.dead load | 0 | kg | |||||
| Rated output | 2.0 | mV/V | |||||
| Rated output tolerance | ± 0.2 | mV/V | |||||
| Pepeatability | ± 0.010 | ± 0.010 | ± 0.006 | ± 0.005 | % of AL* | ||
| Creep 30 minute | ± 0.017 | ± 0.017 | ± 0.0010 | ± 0.0083 | % of AL | ||
| Temp. effect on rated output +20...+40℃ | ± 0.00175 | ± 0.00175 | ± 0.00105 | ± 0.00087 | % of Emax/℃ | ||
| -10...+20℃ | ± 0.00117 | ± 0.00117 | ± 0.0007 | ± 0.00058 | % of AL/℃ | ||
| Temp. effect on zero balance | ± 0.0028 | ± 0.0014 | % of Emax/℃ | ||||
| Hysteresis error | ± 0.0175 | ± 0.0175 | ± 0.0105 | ± 0.0105 | % of Emax | ||
| Non-linearity error | ± 0.0175 | ± 0.0175 | ± 0.0105 | ± 0.0105 | % of Emax | ||
| Min. dead load output return | ± 0.0166 | ± 0.0166 | ± 0.0100 | ± 0.0083 | % of AL | ||
| Offer center load error (OIML R76) | ± 0.0044 | ± 0.0044 | ± 0.0026 | ± 0.0022 | % of AL/cm | ||
| Input resistance | 404± 15 | Ω | |||||
| Output resistance | 350 ± 3 | Ω | |||||
| Insulation resistance @50VDC | ＞5000 | MΩ | |||||
| Excitation voltage | Recommended | 10 | V AC/DC | ||||
| Maximum | 15 | V AC/DC | |||||
| Temperature range | Compensated | -10 to +40 | ℃ | ||||
| Operating | -10 to +50 | ℃ | |||||
| Safe storage | -25 to +70 | ℃ | |||||
| Load limit | Safe | 150 | % of Emax | ||||
| Ultimate | 300 | % of Emax | |||||
| Protection | Type | Silicone rubber over gage | |||||
| IP rating | IP65 | ||||||
| OIML / European Approval | OIML Cert. No. | R60/2017-A-NL1-21.23 | |||||
| European Cert. No. | TC11565 | ||||||
| Class | C6 | ||||||
| nmax | 6000 | ||||||
| NTEP Approval | Cert. No. | 23-026 | |||||
| Class | Ⅲ | ||||||
| nmax | 6000 | ||||||
| Cable | Length | 2.5 | m | ||||
| Type | 4 or 6 cores, PVC | ||||||
| Construction | Aluminium | ||||||
| Maximum platform size | 600×800 | mm | |||||
| Recommended torque | 50kg to 300kg: 25.0/ above 300kg: 30.0 | N.m | |||||
| Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load. | |||||||
