AL150
HOLI
CE, OIML, NTEP, RoHS
Availability: | |
---|---|
Quantity: | |
Capacity: 30kg to 500kg
The AL150 load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. The AL150 stands distinctively ahead in the arena of high-precision load cells. Crafted with meticulous attention to detail, it guarantees exceptional accuracy, making it an indispensable asset for any weighing requirement.
Model | Products Description |
AL 150-60kg | OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-100kg | OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-200kg | OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-300kg | OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-500kg | OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-130lb | NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-220lb | NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-330lb | NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-440lb | NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-660lb | NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
AL 150-1100lb | NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores. |
Aluminium Single-Point Load Cell AL150 | |||||||
Parameter | Specifications | Units | |||||
Rated capacity (Emax) | 60 /100 / 200/ 300/ 500 | kg | |||||
130/ 220 / 330 /440 / 660 / 1100 | lb | ||||||
Accuracy class | C3 | C3MR | C5 | C6 | |||
Maximum number of LC intervals (Nmax) | 3000 | 2*3000 | 5000 | 6000 | |||
Min. LC verification interval (Vmin) | Emax / 5000 | Emax / 10000 | g | ||||
Zero balance | ±0.1 | mV/V | |||||
Min.dead load | 0 | kg | |||||
Rated output | 2.0 | mV/V | |||||
Rated output tolerance | ± 0.2 | mV/V | |||||
Pepeatability | ± 0.010 | ± 0.010 | ± 0.006 | ± 0.005 | % of AL* | ||
Creep 30 minute | ± 0.017 | ± 0.017 | ± 0.0010 | ± 0.0083 | % of AL | ||
Temp. effect on rated output +20...+40℃ | ± 0.00175 | ± 0.00175 | ± 0.00105 | ± 0.00087 | % of Emax/℃ | ||
-10...+20℃ | ± 0.00117 | ± 0.00117 | ± 0.0007 | ± 0.00058 | % of AL/℃ | ||
Temp. effect on zero balance | ± 0.0028 | ± 0.0014 | % of Emax/℃ | ||||
Hysteresis error | ± 0.0175 | ± 0.0175 | ± 0.0105 | ± 0.0105 | % of Emax | ||
Non-linearity error | ± 0.0175 | ± 0.0175 | ± 0.0105 | ± 0.0105 | % of Emax | ||
Min. dead load output return | ± 0.0166 | ± 0.0166 | ± 0.0100 | ± 0.0083 | % of AL | ||
Offer center load error (OIML R76) | ± 0.0044 | ± 0.0044 | ± 0.0026 | ± 0.0022 | % of AL/cm | ||
Input resistance | 404± 15 | Ω | |||||
Output resistance | 350 ± 3 | Ω | |||||
Insulation resistance @50VDC | >5000 | MΩ | |||||
Excitation voltage | Recommended | 10 | V AC/DC | ||||
Maximum | 15 | V AC/DC | |||||
Temperature range | Compensated | -10 to +40 | ℃ | ||||
Operating | -10 to +50 | ℃ | |||||
Safe storage | -25 to +70 | ℃ | |||||
Load limit | Safe | 150 | % of Emax | ||||
Ultimate | 300 | % of Emax | |||||
Protection | Type | Silicone rubber over gage | |||||
IP rating | IP65 | ||||||
OIML / European Approval | OIML Cert. No. | R60/2017-A-NL1-22.22 | |||||
European Cert. No. | TC11564 | ||||||
Class | C6 | ||||||
nmax | 6000 | ||||||
NTEP Approval | Cert. No. | 23-027 | |||||
Class | Ⅲ | ||||||
nmax | 6000 | ||||||
Cable | Length | 1.5 | m | ||||
Type | 4 or 6 cores, PVC | ||||||
Construction | Aluminium | ||||||
Maximum platform size | 400×500 | mm | |||||
Recommended torque | 14.0 | N.m | |||||
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load. |
