AL130 - the Pinnacle of Precision: The HOLI Scale AL130 Single Point Load Cell

Name: AL130 - the Pinnacle of Precision: The HOLI Scale AL130 Single Point Load Cell
Brand: HOLI
Rating: 5.0 (56 reviews)

Discover the unmatched precision and reliability of the HOLI Scale AL130 Load Cell, a top-tier single-point aluminium weighing solution. OIML certified and backed by HOLI Scale's industry-leading expertise, this load cell is designed for diverse weighing applications, ensuring accuracy and consistency. Dive into the forefront of weighing technology with AL130.

Model:
AL130
Brand:
HOLI
Certificates:
CE, OIML, NTEP, RoHS

Availability:

Quantity:



Inquiry Contact Now

Product Description

Product Description:

Capacity: 3kg to 50kg

The AL130 load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. Made from durable aluminium alloy steel, it offers excellent environmental resistance and long-term stability. The compact size and lightweight design of it make them easy to integrate into various systems and equipment.

Key Features:

Reliable single point load cell design for even weight distribution
Made from durable aluminium alloy steel for light weight and high strength
Smooth anodized surface for protection and long-lasting use
Fully OIML Approved and NTEP Approved for trusted performance
Ideal for many scale parts like bench scales, postal scales, and retail weighing systems

The AL130 delivers excellent value, quality, and reliability – a smart choice for any weighing setup.

Model	Products Description
AL 130-3kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-5kg-	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-10kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-15kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-20kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-30kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-40kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-50kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-6.6lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-22lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-44lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-66lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-88lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130-110lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores

Product dimensions:

AL130

Aluminium Single-Point Load Cell AL 130
Parameter		Specifications				Units
Rated capacity (Emax)		3 /5 / 10/ 15/ 20/ 30/ 40/ 50				kg
		6.6/ 22 / 44 /66 / 88 / 110				lb
Accuracy class		C3	C3MR	C5	C6
Maximum number of LC intervals (Nmax)		3000	2*3000	5000	6000
Min. LC verification interval (Vmin)		Emax / 5000	Emax / 10000			g
Zero balance		± 0.1				mV/V
Min.dead load		0				kg
Rated output		2.0				mV/V
Rated output tolerance		± 0.2				mV/V
Pepeatability		± 0.010	± 0.010	± 0.006	± 0.005	% of AL*
Creep 30 minute		± 0.017	± 0.017	± 0.0010	± 0.0083	% of AL
Temp. effect on rated output +20...+40℃		± 0.00175	± 0.00175	± 0.00105	± 0.00087	% of Emax/℃
-10...+20℃		± 0.00117	± 0.00117	± 0.0007	± 0.00058	% of AL/℃
Temp. effect on zero balance		± 0.0028	± 0.0014			% of Emax/℃
Hysteresis error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Non-linearity error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Min. dead load output return		± 0.0166	± 0.0166	± 0.0100	± 0.0083	% of AL
Offer center load error (OIML R76)		± 0.0044	± 0.0044	± 0.0026	± 0.0022	% of AL/cm
Input resistance		404± 15				Ω
Output resistance		350 ± 3				Ω
Insulation resistance @50VDC		＞5000				MΩ
Excitation voltage	Recommended	10				V AC/DC
	Maximum	15				V AC/DC
Temperature range	Compensated	-10 to +40				℃
	Operating	-10 to +50				℃
	Safe storage	-25 to +70				℃
Load limit	Safe	150				% of Emax
	Ultimate	300				% of Emax
Protection	Type	Silicone rubber over gage
	IP rating	IP65
OIML / European Approval	OIML Cert. No.	R60/2017-A-NL1-22.21
	European Cert. No.	TC11563
	Class	C6
	nmax	6000
NTEP Approval	Cert. No.	23-028
	Class	Ⅲ
	nmax	6000
Cable	Length	1.5				m
	Type	4 or 6 cores, PVC
Construction		Aluminium
Maximum platform size		250×300 for 3 to 10kg; 300×350 for 20 to 50kg				mm
Recommended torque		10.0				N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load.
