AL150W - Mastering Precision and Robustness: The HOLI Scale AL150W Single Point Load Cell

Name: AL150W - Mastering Precision and Robustness: The HOLI Scale AL150W Single Point Load Cell
Brand: HOLI
Rating: 5.0 (98 reviews)

Discover the prowess of HOLI Scale's AL150W load cell - a widened masterpiece in weighing technology. Crafted in top-grade aluminium, this load cell offers precise measurements up to 500kg. Choose the AL150W for unparalleled accuracy in a robust, broad-based design.

Model:
AL150W
Brand:
HOLI
Certificates:
CE, OIML, NTEP, RoHS

Availability:

Quantity:



Inquiry Contact Now

Product Description

Product Description：

Capacity: 30kg to 500kg

The AL150W load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. The weighing industry continues its relentless march towards perfection. Leading this parade is the AL150W load cell by HOLI Scale, an embodiment of precision coupled with robust design.

Model	Products Description
AL 150W-60kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-100kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-200kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-300kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-500kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-220lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-440lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-660lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-880lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-1100lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

Product dimensions(mm):

Al150w

Aluminium Single-Point Load Cell AL150W
Parameter		Specifications				Units
Rated capacity (Emax)		60 /100 / 200/ 300/ 500				kg
		220/ 440/ 660/ 880/ 1100				lb
Accuracy class		C3	C3MR	C5	C6
Maximum number of LC intervals (Nmax)		3000	2*3000	5000	6000
Min. LC verification interval (Vmin)		Emax / 5000	Emax / 10000			g
Zero balance		±0.1				mV/V
Min.dead load		0				kg
Rated output		2.0				mV/V
Rated output tolerance		± 0.2				mV/V
Pepeatability		± 0.010	± 0.010	± 0.006	± 0.005	% of AL*
Creep 30 minute		± 0.017	± 0.017	± 0.0010	± 0.0083	% of AL
Temp. effect on rated output +20...+40℃		± 0.00175	± 0.00175	± 0.00105	± 0.00087	% of Emax/℃
-10...+20℃		± 0.00117	± 0.00117	± 0.0007	± 0.00058	% of AL/℃
Temp. effect on zero balance		± 0.0028	± 0.0014			% of Emax/℃
Hysteresis error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Non-linearity error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Min. dead load output return		± 0.0166	± 0.0166	± 0.0100	± 0.0083	% of AL
Offer center load error (OIML R76)		± 0.0044	± 0.0044	± 0.0026	± 0.0022	% of AL/cm
Input resistance		404± 15				Ω
Output resistance		350 ± 3				Ω
Insulation resistance @50VDC		＞5000				MΩ
Excitation voltage	Recommended	10				V AC/DC
	Maximum	15				V AC/DC
Temperature range	Compensated	-10 to +40				℃
	Operating	-10 to +50				℃
	Safe storage	-25 to +70				℃
Load limit	Safe	150				% of Emax
	Ultimate	300				% of Emax
Protection	Type	Silicone rubber over gage
	IP rating	IP65
OIML / European Approval	OIML Cert. No.	R60/2017-A-NL1-22.22
	European Cert. No.	TC11564
	Class	C6
	nmax	6000
NTEP Approval	Cert. No.	23-027
	Class	Ⅲ
	nmax	6000
Cable	Length	1.5				m
	Type	4 or 6 cores, PVC
Construction		Aluminium
Maximum platform size		400×500				mm
Recommended torque		14.0				N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load.
