AL130L - Precision Weighing with Distinct Dimensions Single Point Load Cell

Name: AL130L - Precision Weighing with Distinct Dimensions Single Point Load Cell
Brand: HOLI
Rating: 5.0 (27 reviews)

Dive into the world of precision weighing with HOLI Scale's AL130L load cell. With unique dimensions and crafted from durable aluminium, the AL130L stands distinct from its counterpart, the AL130. OIML/NTEP certified and designed for specialized weighing needs, discover how this single-point load cell offers both accuracy and flexibility in industrial applications.

Model:
AL130L
Brand:
HOLI
Certificates:
CE, OIML, NTEP, RoHS

Availability:

Quantity:



Inquiry Contact Now

Product Description

Product Description：

Capacity: 3kg to 100kg

The AL130L load cell from HOLI Scale is a high-precision, single point load cell certified by 3000 divisions and Class III. Besides its excellent durability and longevity, it also offers a wide range of models with load capacities spanning from 3kg to 100kg. This versatility allows users to select the most appropriate model for their specific application needs, ensuring optimal performance and cost-effectiveness.

Model	Products Description
AL 130L-3kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-5kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-10kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-15kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-20kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-30kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-40kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-50kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-6.6lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-22lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-44lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-66lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-88lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-110lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores

Product dimensions:

Aluminium Single-Point Load Cell AL 130L
Parameter		Specifications				Units
Rated capacity (Emax)		3/ 5/ 10/ 15/ 20/ 30/ 40/ 50/ 100				kg
		6.6/ 22 / 44 / 110/ 220 / 330				lb
Accuracy class		C3	C3MR	C5	C6
Maximum number of LC intervals (Nmax)		3000	2*3000	5000	6000
Min. LC verification interval (Vmin)		Emax / 5000	Emax / 10000			g
Zero balance		± 0.1				mV/V
Min.dead load		0				kg
Rated output		2.0				mV/V
Rated output tolerance		± 0.2				mV/V
Pepeatability		± 0.010	± 0.010	± 0.006	± 0.005	% of AL*
Creep 30 minute		± 0.017	± 0.017	± 0.0010	± 0.0083	% of AL
Temp. effect on rated output +20...+40℃		± 0.00175	± 0.00175	± 0.00105	± 0.00087	% of Emax/℃
-10...+20℃		± 0.00117	± 0.00117	± 0.0007	± 0.00058	% of AL/℃
Temp. effect on zero balance		± 0.0028	± 0.0014			% of Emax/℃
Hysteresis error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Non-linearity error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Min. dead load output return		± 0.0166	± 0.0166	± 0.0100	± 0.0083	% of AL
Offer center load error (OIML R76)		± 0.0044	± 0.0044	± 0.0026	± 0.0022	% of AL/cm
Input resistance		404± 15				Ω
Output resistance		350 ± 3				Ω
Insulation resistance @50VDC		＞5000				MΩ
Excitation voltage	Recommended	10				V AC/DC
	Maximum	15				V AC/DC
Temperature range	Compensated	-10 to +40				℃
	Operating	-10 to +50				℃
	Safe storage	-25 to +70				℃
Load limit	Safe	150				% of Emax
	Ultimate	300				% of Emax
Protection	Type	Silicone rubber over gage
	IP rating	IP65
OIML / European Approval	OIML Cert. No.	R60/2017-A-NL1-22.21
	European Cert. No.	TC11563
	Class	C6
	nmax	6000
NTEP Approval	Cert. No.	23-028
	Class	Ⅲ
	nmax	6000
Cable	Length	1.5				m
	Type	4 or 6 cores, PVC
Construction		Aluminium
Maximum platform size		250×300 for 3 to 10kg; 300×350 for 20 to 50kg				mm
Recommended torque		10.0				N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load.
