6 digits 0.56" LED display.
Support 1 analog scale platform access, up to 12 load cells supported.
CPA 6000e certification accuracy, supporting up to 150000 display divisions.
Standard 1 RS232 or RS485, supporting MODBUS-RTU.
Optional Ethernet port, supporting MODBUS-TCP.
PLC communication interface options:
⁎PROFBIBUS-DP(Siemens PLC).
⁎PROFINET(Dual network port, built-in switch, Siemens PLC).
⁎EtherNet/IP(Dual network port, built-in switch, Rockwell PLC,Delta PLC) CC-link(Mitsubishi PLC), 1 channel (16-bit precision DAC) analog output type can be switched by parameters,
4~20mA/ 0~20mA/ 0~24mA/ 0~5V/ 0~10V.
Input/ output interface:
⁎One input with photoisolation and two transistor outputs with photoisolation.
Multiple calibration modes:
⁎Supports up to 3 point weight calibration.
⁎Weightless calibration.
⁎Remote calibration through PLC communication interface.
Support applications:
⁎Basic weighing version.
⁎Supports dual speed preset point control and optional 8 simple comparison outputs.
⁎Lower/upper limit material level detection.
⁎The working power supply supports DC 24VDC± 5%, and the maximum power.
Technical parameter: | |
Switching power supply | DC24V±5% |
Working temperature | -10℃~40℃ |
Humidity | ≤90%R.H |
| Nonlinearity | ≤0.01%F.S |
Installation method | 35mm guide rail installation |
| Power dissipation | 6W |
| Load cell power supply | DC: 5V 200mA(MAX) |
| Load cell interface | 6 wire system, long wire automatic compensation |
| Input impedance | 10MΩ |
| Display | 6-digits red LED |
| Zero adjustment range | 0.00-12mV(3mV/ V load cell) |
Input sensitivity | 0.1μV/d |
| Input range | 0.00～15mV(3mV/V load cell) |
| Transform Mode | Sigma -Delta |
| A/D conversion speed | 15、30、60、120、240、480、960 times/ second |
| Gain drift | 10PPM/℃ |
| Maximum display accuracy | 1/100000 |
| Dimension | Case: 110×62×80(mm) |
