Aluminum or mild steel case.
3 analog output modes selected.
Function of alarm for upper and lower limit.
Time and date function.
Peak value holding function.
Tare weighing function.
Highly interference resistant.
Standard Power Supply: Power Cord.
| Explosion-proof class | Ex db[ia IIC Ga] IIB T6 Gb/ Ex tb IIIC 80℃ Db |
| Accuracy Class | Ⅲ |
Input signal scope | -19mv/V~+19mv/V |
No.of Load cell | 1-8pcs Load cells, 350Ω |
Load cell power suppl | DC 5V 350mA |
Division value | 1/2/5/10/20/50/100 optional |
| Display | 7 digits with 0.5″ (LED) |
| Communication Port | RS232/ RS485/ 4-20ma simulator signal |
| Power supply | AC 187~242V, 50/60Hz 1A |
| Working temperature | 0°C~40°C |
| Storage temperature | -20°C~50°C |
| Relative humidity | ≤ 90%RH |
Aluminum or mild steel case.
3 analog output modes selected.
Function of alarm for upper and lower limit.
Time and date function.
Peak value holding function.
Tare weighing function.
Highly interference resistant.
Standard Power Supply: Power Cord.
| Explosion-proof class | Ex db[ia IIC Ga] IIB T6 Gb/ Ex tb IIIC 80℃ Db |
| Accuracy Class | Ⅲ |
Input signal scope | -19mv/V~+19mv/V |
No.of Load cell | 1-8pcs Load cells, 350Ω |
Load cell power suppl | DC 5V 350mA |
Division value | 1/2/5/10/20/50/100 optional |
| Display | 7 digits with 0.5″ (LED) |
| Communication Port | RS232/ RS485/ 4-20ma simulator signal |
| Power supply | AC 187~242V, 50/60Hz 1A |
| Working temperature | 0°C~40°C |
| Storage temperature | -20°C~50°C |
| Relative humidity | ≤ 90%RH |
