The process control weighing instrument has the characteristics of high speed and efficiency, complete functions, reliability and stability, fully reflecting the leading product technology and exquisite manufacturing process of Hongli Company. Can meet the complex and harsh industrial weighing control requirements. Suitable for multiple control scenarios such as weighing and measuring display, packaging, filling, and batching in hazardous chemical environments.
Double row 6-digit 0.25"LED segment code display.
Supports access to 1 analog weighing platform, with a maximum of 12pcs 350Ω load cells.
PLC communication interface options.
1channel(16-bit precision DAC) analog output, the type can be switched through the menu 4~20mA/0~20mA/0~24mA/0~5V/0~10V .
2 isolated inputs, 3 relay outputs.
Multiple calibration modes:
⁎ Supports up to 3 point weight calibration .
⁎ Weightless calibration.
⁎ Remote calibration through PLC. communication interface.
Support applications:
⁎ Basic weighing version.
⁎ Supports dual speed preset point control and optional 8 simple comparison outputs.
⁎ Lower/upper limit material level detection.
⁎The working power supply supports DC 24VDC±5%, and the maximum power consumption of the entire machine is less than 6W.
Technical parameter: | |
Switching power supply | DC24V±5% |
Working temperature | -10℃~40℃ |
Humidity | ≤90%R.H |
| Nonlinearity | ≤0.01%F.S |
Installation method | 35mm guide rail installation |
| Power dissipation | 6W |
| Load cell power supply | DC:5V200mA(MAX) |
| Load cell interface | long wire automatic compensation |
| Input impedance | 10MΩ |
| Display | Double row 6-digit LED |
| Zero adjustment range | 0.00-12mV(3mV/ Vload cell |
Input sensitivity | 0.1μV/d |
| Input range | 0.00～15mV(3mV/V load cell) |
| Transform Mode | Sigma -Delta |
| A/D conversion speed | 240 times/ second |
| Gain drift | 10PPM/℃ |
| Maximum display accuracy | 1/100000 |
| Dimension | Case: 123.5×45×99.5(mm) |
