The process control weighing instrument has the characteristics of high speed and high efficiency, complete functions, reliable and stable, which can meet the complex and harsh industrial weighing control needs, and is suitable for many control occasions such as weighing and measuring display, packaging, filling and batching in chemical dangerous occasions with narrow space and difficult wiring.
With the function of 4 single channel meters, saving space.
Optional 1-4 load cell interfaces, each supporting up to 6 load cells.
PLC Communication interface option:
⁎PROFINET (Dual network port, built-in switch, Siemens PLC).
⁎EtherNet/IP(Dual network port, built-in switch, Rockwell PLC, Delta PLC).
⁎EtherCAT、MODBUS-TCP(Network port version only).
⁎PROFIBUS-DP (Siemens PLC)、CANopen、CC-link(Mitsubishi PLC).
Multiple calibration modes:
⁎Supports up to 3 point weight calibration .
⁎Weightless calibration.
⁎Remote calibration through PLC communication interface.
Support applications:
⁎Basic weighing version
⁎Supports dual speed preset point control and optional 8 simple comparison outputs .
⁎Lower/upper limit material level detection.
⁎The working power supply supports DC 24VDC±5%, and the maximum power consumption of the entire machine is less than 6w.
Technical parameter: | |
Switching power supply | DC24V±5% |
Working temperature | -10℃~40℃ |
Humidity | ≤90%R.H |
| Nonlinearity | ≤0.01%F.S |
Installation method | 35mm guide rail installation |
| Power dissipation | 6W |
| Load cell power supply | DC: 5V 200mA(MAX) |
| Load cell interface | 6 wire system, long wire automatic compensation |
| Input impedance | 10MΩ |
| Display | Double row 6-digit LED |
| Zero adjustment range | 0.00-12mV(3mV/ V load cell) |
Input sensitivity | 0.1μV/d |
| Input range | 0.00～15mV(3mV/V load cell) |
| Transform Mode | Sigma -Delta |
| A/D conversion speed | 240 times/ second |
| Gain drift | 10PPM/℃ |
| Maximum display accuracy | 1/100000 |
| Dimension | Case: 123.5×45×99.5(mm) |
