Process control weighing indicator can be easily connected with resistance strain gauge sensor to form batching scale, quantitative packaging scale, control scale, upper and lower limit weighing alarm device, etc.,suitable for a variety of high speed and high precision weighing requirements of the control occasions.
6-digit integrated addition scale, subtraction scale, sorting scale, upper and lower limit alarm and other functions, with 3 external control input and 3 control output.
Standard asynchronous serial communication interface(RS232 or RS485), flexible communication methods(continuous sending, instruction response ,and MODBUS RTUS).
4~20mA (or 0~5V or 0~10V)analog precision output.
Upper and lower alarm output Settings.
High precision A/D conversion, readability up to 1/30000.
Debug parameters are quickly saved and quickly recovered.
Changing the indicator does not require recalibration, just input the parameters of the original indicator.
Large screen display output.
Flexible peak holding function.
It can be connected to a serial printer to print weighing records, cumulative measurements, or formulas. Manual or automatic printing is optional.
With the peeling function, choose whether to automatically peel at the start of the automatic control. The digital filtering intensity of AD/data can be set and changed as needed.
Multiple operation information and error message prompts.
Print unit selection: kg, t, g, Ib.
With accurate clock, calendar, automatic leap year, leap month, not affected by power outages.
Strong anti-interference performance, high reliability.
Technical parameter: | |
| Accuracy | C3, n=6000 |
| Input signal range | -19mV~+19mV |
Nonlinearity | ≤0.01%F.S |
| Number of load cells | 1~8pcs 350Ω load cell |
| Power supply | DC: 5V; 350mA |
| Connecting way | 6-wire system, long wire automatic compensation |
Display | Single row 7-bit 0.8" LED,11 status indicators |
| Division | 1/ 2/ 5/ 10/ 20/ 50/ 100 optional |
Clock | Can display real-time time and date |
| Keyboard | With 5 tap keys |
| Screen display interface | Serial output mode, 20mA constant current source signal |
| Communication interface | Serial RS232/RS485(either one);Baud rate 600~9600 optional |
| Print interface | Shared with serial port,can connect to serial printer |
| Relay output | Contact capacity AC:21/259V DC:21/30 |
External control input | 15, 30, 60, 120, 480, 960 times/second |
| Using power | AC 187~242V, 50/60Hz 1A/ DC 24V |
| Working temperature | -10℃~40℃ |
| Storage temperature | -20℃~50℃ |
| Humidity | ≤90%RH |
| Dimension | Case:185×91×136(mm)Panel: 220×110×2(mm) |
| Weight | 500g |
