AL150W - Mastering Precision and Robustness: The HOLI Scale AL150W Single Point Load Cell
OIML/NTEP Single Point
AL150W - Mastering Precision and Robustness: The HOLI Scale AL150W Single Point Load Cell
Discover the prowess of HOLI Scale's AL150W load cell - a widened masterpiece in weighing technology. Crafted in top-grade aluminium, this load cell offers precise measurements up to 500kg. Choose the AL150W for unparalleled accuracy in a robust, broad-based design.
Model:AL150W
Brand:HOLI
Certificates:CE, OIML, NTEP, RoHS
Request a Quote

Files & Downloads

Share

Product Description

Capacity: 30kg to 500kg

The AL150W load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. The weighing industry continues its relentless march towards perfection. Leading this parade is the AL150W load cell by HOLI Scale, an embodiment of precision coupled with robust design.


Key Features:

  • Precise and stable single point load cell

  • Made from strong aluminium alloy steel

  • Long-lasting anodized surface for added protection

  • OIML Approved and NTEP Approved for trusted quality

  • Ideal for platform scales, bench scales, and other scale parts


Choose the AL150W for smart weighing solutions that combine accuracy and durability with trusted international certifications.


ModelProducts Description
AL 150W-60kgOIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-100kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 150W-200kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 150W-300kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 150W-500kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 150W-220lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-440lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-660lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-880lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150W-1100lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.


Product dimensions(mm):

AL150W - Mastering Precision and Robustness: The HOLI Scale AL150W Single Point Load Cell

Aluminium Single-Point Load Cell AL150W
ParameterSpecificationsUnits
Rated capacity (Emax)60 /100 / 200/ 300/ 500kg
220/ 440/ 660/ 880/ 1100lb
Accuracy classC3C3MRC5C6
Maximum number of LC intervals (Nmax)30002*300050006000
Min. LC verification interval (Vmin)Emax / 5000Emax / 10000g
Zero balance±0.1mV/V
Min.dead load
0
kg
Rated output2.0mV/V
Rated output tolerance± 0.2mV/V
Pepeatability± 0.010± 0.010± 0.006± 0.005% of AL*
Creep 30 minute
± 0.017± 0.017± 0.0010± 0.0083% of AL
Temp. effect on rated output  +20...+40℃± 0.00175± 0.00175± 0.00105± 0.00087% of Emax/℃
-10...+20℃± 0.00117± 0.00117± 0.0007± 0.00058% of AL/℃
Temp. effect on zero balance± 0.0028± 0.0014% of Emax/℃
Hysteresis error± 0.0175± 0.0175± 0.0105± 0.0105% of Emax
Non-linearity error± 0.0175± 0.0175± 0.0105± 0.0105% of Emax
Min. dead load output return± 0.0166± 0.0166± 0.0100± 0.0083% of AL
Offer center load error (OIML R76)
± 0.0044± 0.0044± 0.0026± 0.0022% of AL/cm
Input resistance404± 15Ω
Output resistance350 ± 3Ω
Insulation resistance @50VDC>5000
Excitation voltageRecommended10V AC/DC
Maximum15V AC/DC
Temperature rangeCompensated-10 to +40
Operating-10 to +50
Safe storage-25 to +70
Load limitSafe150% of Emax
Ultimate300% of Emax
ProtectionType

Silicone rubber over gage


IP ratingIP65
OIML / European ApprovalOIML Cert. No.R60/2017-A-NL1-22.22

European Cert. No.TC11564

ClassC6
nmax6000
NTEP ApprovalCert. No.23-027
Class
nmax6000
CableLength1.5m
Type4 or 6 cores, PVC
ConstructionAluminium
Maximum platform size400×500mm
Recommended torque14.0N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60.

*AL: Applied load.
