AL150Q Single Point Load Cell

Explore the distinction of HOLI Scale's AL150Q load cell, a masterpiece in the revered AL150 series. Marrying high-accuracy weighing up to 500kg with a unique design, the AL150Q stands out even amongst its elite peers, the AL150 and AL150W. Dive into a world of precision with HOLI Scale's latest offering.
Model:AL150Q
Brand:HOLI
Certificates:CE, OIML, NTEP, RoHS

Request a Quote

Files & Downloads

Load cell


Product Description



Capacity: 30kg to 500kg

The AL150Q load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. The AL150Q sensor is a highly regarded weighing sensor that offers a combination of precision, durability, and versatility. Designed specifically for platform scale applications, this load cell is widely used across various industries, including commercial, industrial, and medical sectors.

Key Features:

High-precision single point load cell
Strong aluminium alloy steel construction
Durable anodized coating
Certified: OIML Approved, NTEP Approved
Ideal for retail scales, bench scales, and other scale parts

Whether you're upgrading your scale parts or building a new system, the AL150Q delivers dependable performance every time.

Model	Products Description
AL 150Q-60kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150Q-100kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150Q-200kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150Q-300kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150Q-500kg	OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150Q-220lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 150Q-440lb	NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

Product dimensions(mm):

Aluminium Single-Point Load Cell AL150Q
Parameter		Specifications				Units
Rated capacity (Emax)		60 /100 / 200/ 300/ 500				kg
		220/ 440				lb
Accuracy class		C3	C3MR	C5	C6
Maximum number of LC intervals (Nmax)		3000	2*3000	5000	6000
Min. LC verification interval (Vmin)		Emax / 5000	Emax / 10000			g
Zero balance		±0.1				mV/V
Min.dead load		0				kg
Rated output		2.0				mV/V
Rated output tolerance		± 0.2				mV/V
Pepeatability		± 0.010	± 0.010	± 0.006	± 0.005	% of AL*
Creep 30 minute		± 0.017	± 0.017	± 0.0010	± 0.0083	% of AL
Temp. effect on rated output +20...+40℃		± 0.00175	± 0.00175	± 0.00105	± 0.00087	% of Emax/℃
-10...+20℃		± 0.00117	± 0.00117	± 0.0007	± 0.00058	% of AL/℃
Temp. effect on zero balance		± 0.0028	± 0.0014			% of Emax/℃
Hysteresis error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Non-linearity error		± 0.0175	± 0.0175	± 0.0105	± 0.0105	% of Emax
Min. dead load output return		± 0.0166	± 0.0166	± 0.0100	± 0.0083	% of AL
Offer center load error (OIML R76)		± 0.0044	± 0.0044	± 0.0026	± 0.0022	% of AL/cm
Input resistance		404± 15				Ω
Output resistance		350 ± 3				Ω
Insulation resistance @50VDC		＞5000				MΩ
Excitation voltage	Recommended	10				V AC/DC
	Maximum	15				V AC/DC
Temperature range	Compensated	-10 to +40				℃
	Operating	-10 to +50				℃
	Safe storage	-25 to +70				℃
Load limit	Safe	150				% of Emax
	Ultimate	300				% of Emax
Protection	Type	Silicone rubber over gage
	IP rating	IP65
OIML / European Approval	OIML Cert. No.	R60/2017-A-NL1-22.22
	European Cert. No.	TC11564
	Class	C6
	nmax	6000
NTEP Approval	Cert. No.	23-027
	Class	Ⅲ
	nmax	6000
Cable	Length	1.5				m
	Type	4 or 6 cores, PVC
Construction		Aluminium
Maximum platform size		400×500				mm
Recommended torque		14.0				N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load.
