AL130W - the Superiority of HOLI Scale's AL130W Single Point Load Cell
OIML/NTEP Single Point
AL130W - the Superiority of HOLI Scale's AL130W Single Point Load Cell
Discover the excellence of HOLI Scale's AL130W load cell. Unique in dimensions compared to AL130 & AL130L, this aluminium single-point load cell offers superior precision for diverse weighing applications. Experience accuracy and durability with HOLI Scale's craftsmanship.
Model:AL 130W
Brand:HOLI
Certificates:CE, OIML, NTEP, RoHS
Request a Quote

Files & Downloads

Share

Product Description

Capacity: 40kg to 200kg

The AL130W load cell from HOLI Scale is a high-precision, single point load cell certified by OIML and NTEP. The load cell is designed to be bigger size to withstand heavy loads and frequent use. This durability ensures that it can maintain their accuracy even under demanding conditions, such as heavy industrial environments or high-cycle applications.


Key Features:

  • Precision single point load cell for wider platforms

  • Built with strong aluminium alloy steel for stable and accurate readings

  • Durable anodized coating for protection and long life

  • Certified: OIML Approved and NTEP Approved

  • Great for use in retail, labs, and other scale parts


Choose the AL130W when you need consistent performance in a tough, easy-to-install design.

ModelProducts Description
AL 130W-40kgOIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 130W-50kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 130W-100kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 130W-200kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 130W-66lb

NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 130W-88lb

NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 130W-110lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.

AL 130W-220lb

NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 130W-330lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.
AL 130W-440lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores.


Product dimensions:

AL130W - the Superiority of HOLI Scale's AL130W Single Point Load Cell

Aluminium Single-Point Load Cell AL 130W
ParameterSpecificationsUnits
Rated capacity (Emax)40 /50 / 100/ 200kg
66/ 88 / 110 /220 / 330 / 440lb
Accuracy classC3C3MRC5C6
Maximum number of LC intervals (Nmax)30002*300050006000
Min. LC verification interval (Vmin)Emax / 5000Emax / 10000g
Zero balance±0.1mV/V
Min.dead load
0
kg
Rated output2.0mV/V
Rated output tolerance± 0.2mV/V
Pepeatability± 0.010± 0.010± 0.006± 0.005% of AL*
Creep 30 minute
± 0.017± 0.017± 0.0010± 0.0083% of AL
Temp. effect on rated output  +20...+40℃± 0.00175± 0.00175± 0.00105± 0.00087% of Emax/℃
-10...+20℃± 0.00117± 0.00117± 0.0007± 0.00058% of AL/℃
Temp. effect on zero balance± 0.0028± 0.0014% of Emax/℃
Hysteresis error± 0.0175± 0.0175± 0.0105± 0.0105% of Emax
Non-linearity error± 0.0175± 0.0175± 0.0105± 0.0105% of Emax
Min. dead load output return± 0.0166± 0.0166± 0.0100± 0.0083% of AL
Offer center load error (OIML R76)
± 0.0044± 0.0044± 0.0026± 0.0022% of AL/cm
Input resistance404± 15Ω
Output resistance350 ± 3Ω
Insulation resistance @50VDC>5000
Excitation voltageRecommended10V AC/DC
Maximum15V AC/DC
Temperature rangeCompensated-10 to +40
Operating-10 to +50
Safe storage-25 to +70
Load limitSafe150% of Emax
Ultimate300% of Emax
ProtectionType

Silicone rubber over gage


IP ratingIP65
OIML / European ApprovalOIML Cert. No.R60/2017-A-NL1-22.21

European Cert. No.TC11563

ClassC6
nmax6000
NTEP ApprovalCert. No.23-028
Class
nmax6000
CableLength1.5m
Type4 or 6 cores, PVC
ConstructionAluminium
Maximum platform size300×400mm
Recommended torque10.0N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60.

*AL: Applied load.
