AL130L - Precision Weighing with Distinct Dimensions Single Point Load Cell
OIML/NTEP Single Point
AL130L - Precision Weighing with Distinct Dimensions Single Point Load Cell
Dive into the world of precision weighing with HOLI Scale's AL130L load cell. With unique dimensions and crafted from durable aluminium, the AL130L stands distinct from its counterpart, the AL130. OIML/NTEP certified and designed for specialized weighing needs, discover how this single-point load cell offers both accuracy and flexibility in industrial applications.
Model:AL130L
Brand:HOLI
Certificates:CE, OIML, NTEP, RoHS
Request a Quote

Files & Downloads

Share

Product Description

Capacity: 3kg to 100kg

The AL130L load cell from HOLI Scale is a high-precision, single point load cell certified by 3000 divisions and Class III. Besides its excellent durability and longevity, it also offers a wide range of models with load capacities spanning from 3kg to 100kg. This versatility allows users to select the most appropriate model for their specific application needs, ensuring optimal performance and cost-effectiveness.


Key Features:

  • High-accuracy single point load cell for wider platforms

  • Built from lightweight aluminium alloy steel for strength and stability

  • Anodized surface treatment adds extra resistance against wear

  • Trusted certifications: OIML Approved and NTEP Approved

  • Perfect for many scale parts in trade, lab, and shop applications


The AL130L is a solid solution when you need dependable precision in a compact format. Easy to install, long-lasting, and ready for everyday weighing needs.

ModelProducts Description
AL 130L-3kgOIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-5kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-10kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-15kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-20kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-30kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-40kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-50kg

OIML, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-6.6lb

NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-22lb

NTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores

AL 130L-44lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-66lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-88lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores
AL 130L-110lbNTEP, aluminium alloy steel, 1.5m wire with 4 or 6 cores


Product dimensions:

Aluminium Single-Point Load Cell AL 130L
ParameterSpecificationsUnits
Rated capacity (Emax)

3/ 5/ 10/ 15/ 20/ 30/ 40/ 50/ 100

kg
6.6/ 22 / 44 / 110/ 220 / 330lb
Accuracy classC3C3MRC5C6
Maximum number of LC intervals (Nmax)30002*300050006000
Min. LC verification interval (Vmin)Emax / 5000Emax / 10000g
Zero balance± 0.1mV/V
Min.dead load
0
kg
Rated output2.0mV/V
Rated output tolerance± 0.2mV/V
Pepeatability± 0.010± 0.010± 0.006± 0.005% of AL*
Creep 30 minute
± 0.017± 0.017± 0.0010± 0.0083% of AL
Temp. effect on rated output  +20...+40℃± 0.00175± 0.00175± 0.00105± 0.00087% of Emax/℃
-10...+20℃± 0.00117± 0.00117± 0.0007± 0.00058% of AL/℃
Temp. effect on zero balance± 0.0028± 0.0014% of Emax/℃
Hysteresis error± 0.0175± 0.0175± 0.0105± 0.0105% of Emax
Non-linearity error± 0.0175± 0.0175± 0.0105± 0.0105% of Emax
Min. dead load output return± 0.0166± 0.0166± 0.0100± 0.0083% of AL
Offer center load error (OIML R76)
± 0.0044± 0.0044± 0.0026± 0.0022% of AL/cm
Input resistance404± 15Ω
Output resistance350 ± 3Ω
Insulation resistance @50VDC>5000
Excitation voltageRecommended10V AC/DC
Maximum15V AC/DC
Temperature rangeCompensated-10 to +40
Operating-10 to +50
Safe storage-25 to +70
Load limitSafe150% of Emax
Ultimate300% of Emax
ProtectionType

Silicone rubber over gage


IP ratingIP65
OIML / European ApprovalOIML Cert. No.R60/2017-A-NL1-22.21

European Cert. No.TC11563

ClassC6
nmax6000
NTEP ApprovalCert. No.23-028
Class
nmax6000
CableLength1.5m
Type4 or 6 cores, PVC
ConstructionAluminium
Maximum platform size250×300 for 3 to 10kg; 300×350 for 20 to 50kgmm
Recommended torque10.0N.m
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60.

*AL: Applied load.
