| Specifications | |||||
| Parameter | Value | Units | |||
| Rated capacity (Emax) | 500 / 1000 / 1500 / 2000 | kg | |||
| 500 / 1000 / 1500 / 2000 / 3000 / 4000 / 5000 | lb | ||||
| Accuracy class | C3 | C4 | |||
| Maximum number of LC intervals (nmax) | 3000 | 4000 | |||
| Min. LC verification interval (vmin) | Emax / 5000 | Emax / 10000 | kg | ||
| Temp. effect on zero balance | ± 0.0028 | ± 0.0014 | % of Emax/℃ | ||
| Rated output | 2.0 | mV/V | |||
| Rated output tolerance | ± 0.1 | % of Emax | |||
| Zero balance | ± 1.0 | % of Emax | |||
| Temp. effect on rated output +20…+40℃ | ± 0.00175 | ± 0.0013 | % of AL/℃ | ||
| -10…+20℃ | ± 0.00117 | ± 0.0009 | |||
| Hysteresis error | ± 0.0175 | ± 0.0131 | % of Emax | ||
| Non-linearity error | ± 0.0175 | ± 0.0131 | % of Emax | ||
| Min. dead load output return | ± 0.0166 | ± 0.0125 | % of AL | ||
| Terminal resistance | Excitation | 350 ± 10 | Ω | ||
| Output | 350 ± 3 | Ω | |||
| Insulation resistance @50VDC | ＞5000 | MΩ | |||
| Excitation voltage | Recommended | 10 | V AC/DC | ||
| Maximum | 15 | V AC/DC | |||
| Temperature range | Compensated | -10 to +40 | ℃ | ||
| Operating | -30 to +65 | ℃ | |||
| Safe storage | -40 to +80 | ℃ | |||
| Load limit | Safe | 150 | % of Emax | ||
| Ultimate | 300 | % of Emax | |||
| Protection | Type | Hermetically welded | |||
| IP rating | IP68 | ||||
| OIML / European Approval | OIML Cert. No. | R60-2017-A-NL1-22.04 | |||
| European Cert. No. | TC12252 | ||||
| Class | C6 | ||||
| nmax | 6000 | ||||
| NTEP Approval | Cert. No. | 17-113 | |||
| Class | III | ||||
| nmax | 6000 | ||||
| Cable | Length | 3.1 | m | ||
| Type | 4-wire, PVC | ||||
| Construction | Stainless steel | ||||
| Recommended torque | 98 | N.m | |||
| Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. | |||||
