Specifications | ||||||
Parameter | Value | Units | ||||
Rated capacity (Emax) | 500 / 1000 / 1500 / 2000 | kg | ||||
500 / 1000 / 1500 / 2000 / 3000 / 4000 / 5000 | lb | |||||
Accuracy class | C3 | C4 | C5 | |||
Maximum number of LC intervals (nmax) | 3000 | 4000 | 5000 | |||
Min. LC verification interval (vmin) | Emax / 5000 | Emax / 10000 | kg | |||
Temp. effect on zero balance | ± 0.0028 | ± 0.0014 | % of Emax/℃ | |||
Rated output | 2.0 | mV/V | ||||
Rated output tolerance | ± 0.1 | % of Emax | ||||
Zero balance | ± 1.0 | % of Emax | ||||
Temp. effect on rated output +20…+40℃ | ± 0.00175 | ± 0.0013 | ± 0.00105 | % of AL/℃ | ||
-10…+20℃ | ± 0.00117 | ± 0.0009 | ± 0.0007 | |||
Hysteresis error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax | ||
Non-linearity error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax | ||
Min. dead load output return | ± 0.0166 | ± 0.0125 | ± 0.01 | % of AL | ||
Terminal resistance | Excitation | 350 ± 10 | Ω | |||
Output | 350 ± 3 | Ω | ||||
Insulation resistance @50VDC | >5000 | MΩ | ||||
Excitation voltage | Recommended | 10 | V AC/DC | |||
Maximum | 15 | V AC/DC | ||||
Temperature range | Compensated | -10 to +40 | ℃ | |||
Operating | -30 to +65 | ℃ | ||||
Safe storage | -40 to +80 | ℃ | ||||
Load limit | Safe | 150 | % of Emax | |||
Ultimate | 300 | % of Emax | ||||
Protection | Type | Hermetically welded | ||||
IP rating | IP67 | |||||
OIML / European Approval | OIML Cert. No. | R60-2017-A-NL1-22.04 | ||||
European Cert. No. | TC12252 | |||||
Class | C5 | |||||
nmax | 5000 | |||||
NTEP Approval | Cert. No. | 17-113 | ||||
Class | III | |||||
nmax | 6000 | |||||
Cable | Length | 3.1 | m | |||
Type | 4-wire, PVC | |||||
Construction | Alloy steel | |||||
Recommended torque | 98 | N.m | ||||
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. |
