PAW-B-R
Portable Axle Weighing Scale
PAW-B-R
Model:PAW-B-R
Brand:Holi
Certificates:CE, OIML
Request a Quote

Files & Downloads

Share

Product Description

Wheel & Axle Weigher

PAW-B-R Axle Weigher / Portable Wheel Scale System is the perfect choice for anyone looking to accurately weigh trucks, trailers, and other heavy-duty vehicles. it can consist of 4, 6 or even more weighing pads to adapt to different occasions.


HOLI PAW-B-R Portable Axle Weighing Scale – Lightweight Weighing Scale with Built-in Ramps for Static Weighing

The HOLI PAW-B-R Portable Axle Weighing Scale is a practical and easy-to-use weighing scale designed for quick and reliable static weighing of vehicle axles. With its lightweight construction and built-in ramps, this model offers fast setup and smooth operation wherever you need it.

Ideal for transport, logistics, and mobile inspection stations, this portable axle weighing scale provides accurate axle weight readings without the need for permanent installation. The integrated ramps allow vehicles to roll on and off easily, improving safety and saving time.


Features:

* Durable aluminium construction.

* Lightweight  aluminium construction for easy transportation.

* Low cost,but extreme durability, reliability and repeatable accuracy.

* Built-in ramps for easy truck/tire access.

* Easy-to-use operation, with live weight reading.

* Load cell design, easy maintenance.

* Extremely simple and reliable connection of the scale to the weight indicator, wired or wireless optional

The HOLI PAW-B-R is a smart solution for professionals needing a reliable and portable weighing scale that performs well in the field. Whether you're on-site or on the move, it's the perfect balance of function and convenience.


Static Weighing:

Weighs the whole vehicle and calculates total weight, gives the wheel weight, axle weight and total weight. Consisting of 4, 6, 8 or even more weighing pads and 1 touch screen indicator with built-in printer.


Weighing Pad Specifications

Functional Area Dimension(mm)

500(W)×400(L)

19.7"(W)×15.7"(L)

800(W)×450(L)

31.5"(W)×17.7"(L)

900(W)×500(L)

35.4"(W)×19.7"(L)

Overall Dimension(mm)

500(W)×578(L)×54(H)

19.7"(W)×22.8"(L)×2.1"(H)

800(W)×628(L)×60(H)          800(W)×628(L)×65(H)

31.5"(W)×24.7"(L)×2.4"(H)   31.5"(W)×24.7"(L)×2.6"(H)

900(W)×678(L)×60(H)         900(W)×678(L)×65(H)

35.4"(W)×26.7"(L)×2.4"(H)  35.4"(W)×26.7"(L)×2.6"(H)

Weighing Capacity

≤5t(10,000Ib)

≤10t(20,000lb)        ≤15t(30,000lb)≤10t(20,000lb)        ≤15t(30,000lb)
Load Cell Quantity4pcs6pcs                         8pcs6pcs                         8pcs
Overload Protection150%
150%                       150%150%                       150%
Multi Scales Full Static Accuracy

≤±0.1%

≤±0.1%                   ≤±0.1%

≤±0.1%                   ≤±0.1%
Two Scales Axle Static Accuracy

≤±0.5%

≤±0.5%                   ≤±0.5%

≤±0.5%                   ≤±0.5%
Sensitive Influence by Temperature

0.1%/10℃

0.1%/10℃               0.1%/10℃

0.1%/10℃               0.1%/10℃
Operation Temperature

-10~+65℃

-10~+65℃             -10~+65℃

-10~+65℃             -10~+65℃
Wireless Distance

≤50 Meters

≤50 Meters            ≤50 Meters

≤50 Meters            ≤50 Meters
Working Time

≤30 Hours

≤24 Hours              ≤20 Hours

≤24 Hours              ≤20 Hours

Options

Wired/Wireless

Wired/Wireless       Wired/Wireless

Wired/Wireless       Wired/Wireless
