PAW-B-1
Portable Axle Weighing Scale
PAW-B-1
Model:PAW-B-1
Brand:Holi
Certificates:CE
Request a Quote

Files & Downloads

Share

Product Description

Wheel Weigher

PAW-B-I Portable Wheel Scale is a rugged and reliable weighing solution designed for measuring the weight of trucks and other heavy-duty vehicles. With a lightweight and portable design, this scale system is ideal for use in a variety of applications, including transportation, construction, and mining.


HOLI PAW-B-1 Portable Axle Weighing Scale – Lightweight, Economic Platform Scale for Static Weighing

The HOLI PAW-B-1 Portable Axle Weighing Scale is an economic model designed to deliver accurate and reliable results for static weighing of vehicle axles. This compact platform scale is ideal for those who need a cost-effective and efficient weighing scale that’s easy to carry and use anywhere.

Lightweight and user-friendly, the PAW-B-1  features a built-in digital display, strong aluminium alloy construction, and convenient carry handles. It's perfect for mobile vehicle weighing tasks at transport hubs, inspection points, and temporary job sites.


Features:

* Durable aluminium construction.

* Lightweight aluminium construction for easy transportation.

* Low cost, but extreme durability, reliability and repeatable accuracy.

* Built-in ramps for easy truck/tire access.

* Easy-to-use operation, with live weight reading.

* Load cell design, easy maintenance.

* Built-in digital weight display.

* Backlit display.

* Powered by AAA alkaline high capacity batteries.

Whether you need a simple weighing solution for occasional use or want to expand your weighing options, the HOLI PAW-B-1 Portable Axle Weighing Scale offers great value without compromising on reliability.


Static Weighing:

Weighs the wheels of the vehicle, each wheel with a weighing pad. Consisting of 2, 4, 6 ,8 or even more weighing pads.


Weighing Pad Specifications

Functional Area Dimension(mm)

500(W)×400L)

19.7"(W)×15.7"(L)

800(W)×550(L)

27.5"(W)×11.8"(L)

Overall Dimension(mm)

600(W)×579(L)×56(H)

23.6"(W)×22.8"(L)×2.2"(H)

800(W)×479(L)×56(H)

31.5"(W)×18.9"(L)×2.2"(H)

Weighing Capacity

≤5t(10,000Ib)

≤10t(20,000lb)

One Weighing Pad Weight

19kg
22kg
Load Cell Quantity4pcs6pcs
Overload Protection150%
150%
Single Scale Static Accuracy

≤±0.1%

≤±0.1%

Sensitive Influence by Temperature

0.1%/10℃

0.1%/10℃

Repeatability≤0.01%FS

≤0.01%FS

Operation Temperature

-10~+65℃

-10~+65℃

Working Time

≤30 Hours

≤24 Hours

Direct Display

LCD with Backlight, Function: On/Off. Lb/kg. Zero
