Home / Industry / Forestry / PAW-B-2

Portable Axle Weighing Scale

PAW-B-2

Model:PAW-B-2
Brand:Holi
Certificates:CE

Request a Quote

Files & Downloads

Axle Weighing Scale


Product Description



Wheel & Axle weigher

The lightweight structure is easy to transport and adapt to different situations. It supports both dynamic and static weighing that can resolve weighing issues.

HOLI PAW-B-2 Portable Axle Weighing Scale – Smart Wheel & Axle Weigher for Dynamic and Static Weighing

The HOLI PAW-B-2 Portable Axle Weighing Scale is designed for simple, fast, and accurate weighing of vehicle axles and wheels. Whether you need dynamic or static weighing, this high-performance platform scale delivers consistent and reliable results.

Built with strong materials and a slim, modern design, it is easy to carry and set up anywhere. Each pad functions as a wheel & axle weigher, making it perfect for transport, fleet checks, law enforcement, and logistics.

Features:

* Durable aluminium construction.

* Lightweight aluminium construction for easy transportation.

* Load cell design, easy maintenance.

* Rubber ramps for easy truck/tire access.

* Easy-to-use operation, with live weight reading.

* Built-in digital weight display.

* Backlit display.

The HOLI PAW-B-2 is a reliable and flexible portable axle weighing scale, perfect for professionals who need trusted performance on the go.

Dynamic Weighing With Smart Touch Screen Indicator M6+:

Weighs vehicle axles and calculates total weight, gives the axle weight and total weight. Consisting of 2 weighing pads and 1 touch screen indicator with built-in printer.

Static Weighing:

Weighs the wheels of the vehicle, each wheel with a weighing pad. Consisting of 2, 4, 6, 8 or even more weighing pads.

Weighing Pad Specifications
Functional Area Dimension(mm)	500(W)×400(L) 19.7"(W)×15.7"(L)	800(W)×450(L) 31.5"(W)×17.7"(L)	900(W)×500(L) 35.4"(W)×19.7"(L)
Overall Dimension(mm)	629.5(W)×920(L)×58(H) 24.8"(W)×36.2"(L)×2.3"(H)	929.5(W)×1170(L)×58(H) 36.6"(W)×46.1"(L)×2.3"(H)	1029.5(W)×1220(L)×58(H) 40.5"(W)×48"(L)×2.3"(H)
Rubber Ramp Dimension(mm)	500(W)×205(L) 19.7"(W)×8.1"(L)	800(W)×305(L) 31.5"(W)×12"(L)	900(W)×305(L) 35.4"(W)×12"(L)
Weighing Capacity	≤5t(10,000Ib)	≤10t(20,000lb) ≤15t(30,000lb)	≤10t(20,000lb) ≤15t(30,000lb)
One Weighing Pad Weight	19kg	36kg 43kg	42kg 50kg
Two Rubber Ramps Weight	4kg	17kg 17kg	20kg 20kg
Load Cell Quantity	4pcs	6pcs 8pcs	6pcs 8pcs
Overload Protection	150%	150% 150%	150% 150%
Dynamic Accuracy	≤±3%	≤±3% ≤±3%	≤±3% ≤±3%
Multi Scales Full Static Accuracy	≤±0.1%	≤±0.1% ≤±0.1%	≤±0.1% ≤±0.1%
Two Scales Axle Static Accuracy	≤±0.5%	≤±0.5% ≤±0.5%	≤±0.5% ≤±0.5%
Sensitive Influence by Temperature	0.1%/10℃	0.1%/10℃ 0.1%/10℃	0.1%/10℃ 0.1%/10℃
Repeatability	≤0.01%FS	≤0.01%FS ≤0.01%FS	≤0.01%FS ≤0.01%FS
Operation Temperature	-10~+65℃	-10~+65℃ -10~+65℃	-10~+65℃ -10~+65℃
Wireless Distance	≤50 Meters	≤50 Meters ≤50 Meters	≤50 Meters ≤50 Meters
Working Time	≤45 Hours	≤43 Hours ≤38 Hours	≤43 Hours ≤38 Hours
Direct Display	LCD with Backlight,Function:On/Off.Lb/kg.Zero
