Product description:
The HOLI AS 133 shear beam load cell performs well when used on platform and floor scales. With a threaded load introduction hole, the load cell can easily be used with a threaded foot for levelling.
The hermetically sealed design ensures reliability in most industrial environments. The AS 133 can also be fitted with various accessories making it suitable for platform scales, tanks, batching applications and more.
Key Features:
Built from solid alloy steel and nickel plated for long life
Proven shear beam load cell design for stable readings
Certified as both OIML Approved and NTEP Approved
Ideal for a wide range of scale parts and weighing equipment
Simple to install and very dependable
Whether you're upgrading or replacing your current load cell, the AS133 offers excellent performance and long-term value. A smart solution for any weighing system needing durable and approved parts.
| Model | Products Description |
| AS 133-500kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-1000kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-1500kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-2000kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores |
| AS 133-1000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-1500lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
AS 133-2000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-2500lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-3000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-4000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 133-5000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
Shear Beam Load Cell AS 133 | ||||||
| Parameter | Specifications | Units | ||||
| Rated capacity (Emax) | 500 / 1000 / 1500 / 2000 | kg | ||||
| 1000 / 1500 / 2000 / 2500 / 3000 / 4000 / 5000 | lb | |||||
| Accuracy class | C3 | C4 | C5 | |||
| Maximum number of LC intervals (Nmax) | 3000 | 4000 | 5000 | |||
| Min. LC verification interval (Vmin) | Emax / 5000 | Emax / 10000 | kg | |||
| Zero balance | ± 1.0 | % of Emax | ||||
| Min.dead load | 0 | kg | ||||
| Rated output | 2.0 / 3.0 | mV/V | ||||
| Rated output tolerance | ± 0.1 | % of Emax | ||||
| Pepeatability | ± 0.010 | ± 0.006 | ± 0.006 | % of AL* | ||
| Creep 30 minute | ± 0.017 | ± 0.012 | ± 0.0010 | % of AL | ||
| Temp. effect on rated output +20...+40℃ | ± 0.00175 | ± 0.0013 | ± 0.00105 | % of AL/℃ | ||
| -10...+20℃ | ± 0.00117 | ± 0.0009 | ± 0.0007 | |||
| Temp. effect on zero balance | ±0.0028 | ±0.0014 | % of Emax/℃ | |||
| Hysteresis error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax | ||
| Non-linearity error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax | ||
| Min. dead load output return | ± 0.0166 | ± 0.0125 | ± 0.01 | % of AL | ||
| Excitation resistance | 350 ± 10 | Ω | ||||
| Output resistance | 350 ± 3 | Ω | ||||
| Insulation resistance @50VDC | ＞5000 | MΩ | ||||
| Excitation voltage | Recommended | 10 | V AC/DC | |||
| Maximum | 15 | V AC/DC | ||||
| Temperature range | Compensated | -10 to +40 | ℃ | |||
| Operating | -30 to +65 | ℃ | ||||
| Safe storage | -40 to +80 | ℃ | ||||
| Load limit | Safe | 150 | % of Emax | |||
| Ultimate | 300 | % of Emax | ||||
| Protection | Type | Hermetically welded | ||||
| IP rating | IP67 | |||||
| OIML / European Approval | OIML Cert. No. | R60-2017-A-NL1-22.04 | R60-2017-A-NL1-20-28 | |||
| European Cert. No. | TC12252 | TC10977 | ||||
| Class | C5 | |||||
| nmax | 5000 | |||||
| NTEP Approval | Cert. No. | 23-057 | ||||
| Class | Ⅲ single cell and Class III L, Multiple cell | |||||
| nmax | 4000 | |||||
| Cable | Length | 3 | m | |||
| Type | 4 or 6 cores, PVC | |||||
| Construction | Alloy steel | |||||
| Recommended torque | 98 | N.m | ||||
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load | ||||||
