Capacity: 0.5t to 2t
The AS130 load cell from HOLI Scale is a high-precision, shear beam load cell certified by OIML and NTEP. It is designed for use in various industrial weighing applications, where accuracy and reliability are paramount. Made from durable alloy steel, it offers excellent environmental resistance and long-term stability.
The AS130 is available in multiple capacities, making it versatile for different load requirements.
Features:
Durable alloy steel body with nickel plated finish
Suitable for all kinds of scale parts and systems
Shear beam load cell design for stable and accurate readings
Certified with OIML and NTEP approval for peace of mind
Easy to install and long-lasting
Perfect for industrial and commercial scales, this load cell offers high performance at a great value. Upgrade your system with trusted scale parts that meet the highest standards.
| Model | Products Description |
| AS130-500kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-1000kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-1500kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-2000kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores |
| AS130-1000lb | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-1500lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-2000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-2500lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-3000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-4000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS130-5000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
Product Demensions(mm)
| Shear Beam Load Cell AS130 |
| Parameter | Specifications | Units |
| Rated capacity (Emax) | 500 / 1000 / 1500 / 2000 | kg |
| 1000 / 1500 / 2000 / 2500 / 3000 / 4000 / 5000 | lb |
| Accuracy class | C3 | C4 | C5 |
|
| Maximum number of LC intervals (Nmax) | 3000 | 4000 | 5000 |
|
| Min. LC verification interval (Vmin) | Emax / 5000 | Emax / 10000 | kg |
| Zero balance | ± 1.0 | % of Emax |
Min.dead load
| 0
| kg |
| Rated output | 2.0 / 3.0 | mV/V |
| Rated output tolerance | ± 0.1 | % of Emax |
| Pepeatability | ± 0.010 | ± 0.006 | ± 0.006 | % of AL* |
Creep 30 minute
| ± 0.017 | ± 0.012 | ± 0.0010 | % of AL |
| Temp. effect on rated output +20...+40℃ | ± 0.00175 | ± 0.0013 | ± 0.00105 | % of AL/℃ |
| -10...+20℃ | ± 0.00117 | ± 0.0009 | ± 0.0007 |
| Temp. effect on zero balance | ±0.0028 | ±0.0014 | % of Emax/℃ |
| Hysteresis error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax |
| Non-linearity error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax |
| Min. dead load output return | ± 0.0166 | ± 0.0125 | ± 0.01 | % of AL |
| Excitation resistance | 350 ± 10 | Ω |
| Output resistance | 350 ± 3 | Ω |
| Insulation resistance @50VDC | ＞5000 | MΩ |
| Excitation voltage | Recommended | 10 | V AC/DC |
| Maximum | 15 | V AC/DC |
| Temperature range | Compensated | -10 to +40 | ℃ |
| Operating | -30 to +65 | ℃ |
| Safe storage | -40 to +80 | ℃ |
| Load limit | Safe | 150 | % of Emax |
| Ultimate | 300 | % of Emax |
| Protection | Type | Hermetically welded |
|
| IP rating | IP67 |
|
| OIML / European Approval | OIML Cert. No. | R60-2017-A-NL1-22.04 | R60-2017-A-NL1-20-28 |
|
| European Cert. No. | TC12252 | TC10977 |
|
| Class | C5 |
|
| nmax | 5000 |
|
| NTEP Approval | Cert. No. | 23-057 |
|
| Class | Ⅲ single cell and class III L, Multiple cell |
|
| nmax | 4000 |
|
| Cable | Length | 3 | m |
| Type | 4 or 6 cores, PVC |
|
| Construction | Alloy steel |
|
| Recommended torque | 98 | N.m |
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load |
