The AS203 is a shear beam load cell with high accuracy and a hermetically sealed design to ensure it performs well in harsh industrial environments. It enriches HOLI's product line in platform scales, process weighing and other large format industrial equipment.
Key Features:
Tough alloy steel body with a corrosion-resistant nickel plated finish
Precise and stable shear beam load cell design
Certified as OIML Approved and NTEP Approved for trusted quality
Ideal for various scale parts in industrial or commercial setups
Easy to install, low maintenance, and long-lasting
When you need a reliable load cell that meets high standards and delivers dependable results, the AS203 is an excellent choice.
| Model | Products Description |
| AS 203-500kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-1000kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-1500kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-2000kg | OIML, alloy steel, nickel plated, 3m wire with 4 or 6 cores |
| AS 203-1000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-1500lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
AS 203-2000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-2500lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-3000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-4000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
| AS 203-5000lb | NTEP, alloy steel, nickel plated, 3m wire with 4 or 6 cores. |
Product dimensions:
| Shear Beam Load Cell AS 203 |
| Parameter | Specifications | Units |
| Rated capacity (Emax) | 500 / 1000 / 1500 / 2000 | kg |
| 1000 / 1500 / 2000 / 2500 / 3000 / 4000 / 5000 | lb |
| Accuracy class | C3 | C4 | C5 |
|
| Maximum number of LC intervals (Nmax) | 3000 | 4000 | 5000 |
|
| Min. LC verification interval (Vmin) | Emax / 5000 | Emax / 10000 | kg |
| Zero balance | ± 1.0 | % of Emax |
Min.dead load
| 0
| kg |
| Rated output | 2.0 / 3.0 | mV/V |
| Rated output tolerance | ± 0.1 | % of Emax |
| Pepeatability | ± 0.010 | ± 0.006 | ± 0.006 | % of AL* |
Creep 30 minute
| ± 0.017 | ± 0.012 | ± 0.0010 | % of AL |
| Temp. effect on rated output +20...+40℃ | ± 0.00175 | ± 0.0013 | ± 0.00105 | % of AL/℃ |
| -10...+20℃ | ± 0.00117 | ± 0.0009 | ± 0.0007 |
| Temp. effect on zero balance | ±0.0028 | ±0.0014 | % of Emax/℃ |
| Hysteresis error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax |
| Non-linearity error | ± 0.0175 | ± 0.0131 | ± 0.0105 | % of Emax |
| Min. dead load output return | ± 0.0166 | ± 0.0125 | ± 0.01 | % of AL |
| Excitation resistance | 350 ± 10 | Ω |
| Output resistance | 350 ± 3 | Ω |
| Insulation resistance @50VDC | ＞5000 | MΩ |
| Excitation voltage | Recommended | 10 | V AC/DC |
| Maximum | 15 | V AC/DC |
| Temperature range | Compensated | -10 to +40 | ℃ |
| Operating | -30 to +65 | ℃ |
| Safe storage | -40 to +80 | ℃ |
| Load limit | Safe | 150 | % of Emax |
| Ultimate | 300 | % of Emax |
| Protection | Type | Hermetically welded |
|
| IP rating | IP67 |
|
| OIML / European Approval | OIML Cert. No. | R60-2017-A-NL1-22.04 | R60-2017-A-NL1-20-28 |
|
| European Cert. No. | TC12252 | TC10977 |
|
| Class | C5 |
|
| nmax | 5000 |
|
| NTEP Approval | Cert. No. | 23-057 |
|
| Class | Ⅲ single cell and Class III L, Multiple cell |
|
| nmax | 4000 |
|
| Cable | Length | 3 | m |
| Type | 4 or 6 cores, PVC |
|
| Construction | Alloy steel |
|
| Recommended torque | 98 | N.m |
Notes: The values for linearity, hysteresis and temp. effect on rated output are recommended values, the sum of these data meets the requirements according to OIML R60. *AL: Applied load. |
