Product Description:
Capacity: 30kg to 500kg
The HL6E load cell from HOLI Scale is a high-precision, single point load cell. The HL6E stands distinctively ahead in the area of high-precision load cells. Crafted with meticulous attention to detail, it guarantees exceptional accuracy, making it an indispensable asset for any weighing requirement.
This load cell is rated for Precision C3, meaning it offers trusted accuracy for both personal and industrial applications. Its clever design makes installation quick and easy, saving you time while keeping results spot on.
Key Features:
Made from durable aluminium alloy steel
High-precision performance (rated Precision C3)
Great for bench scales, retail scales, and other scale parts
Easy to fit and reliable to use
Sturdy single structure for long life
If you're looking for a simple, accurate, and long-lasting single point load cell, the HL6E is a top choice that delivers on both quality and value.
| Model | Products Description |
| HL6E-60kg-C3 | Aluminium Alloy steel, C3, 1.5m cable, 4wires. |
| HL6E-100kg-C3 | Aluminium Alloy steel, C3, 1.5m cable, 4wires. |
| HL6E-250kg-C3 | Aluminium Alloy steel, C3, 1.5m cable, 4wires. |
| Qualification | ||
| Load Rating | Kg | 60/100/250 |
| Precision | C3 | |
| Maximum Division | Nmax | 3000 |
| Minimum Division | Vmin | Emax/7000 |
| Composition Error | (%FS) | ≤±0.020 |
| Creep Deformation | (%FS/30min) | ≤±0.0167 |
| The influence of temperature on the output sensitivity | (%FS/10℃) | ≤±0.0175 |
| The influence of temperature on the zero output | (%FS/10℃) | ≤±0.020 |
| Rated Output | (MV/V) | 2.0±0.2 |
| Input impedance | (Ω) | 406±6 |
| Output impedance | (Ω) | 350±3 |
| Insulation Resistance | (MΩ) | ≥5000(50VDC) |
| Zero output | (%FS) | 2 |
| Temperature compensation range | (℃) | -10~+40 |
| Working femperature range | (℃) | -35~+65 |
| Recommend excitation voltage | (V) | 5~12(DC) |
| Maximum excitation voltage | (V) | 18(DC) |
| Safety overload range | (%FS) | 150 |
| Limit overload range | (%FS) | 300 |
| Position Error | 0.02%/100mm | |
