The HOLI HL6D Load cell made from durable aluminium alloy steel, it offers excellent environmental resistance and long-term stability. The compact size and lightweight design of it make them easy to integrate into various systems and equipment.
This load cell is perfect for platform scales, weighing machines, and other scale parts where precision matters. It meets Precision C3 standards, offering consistent and accurate measurements you can rely on.
Key Features:
High-quality aluminium alloy steel construction
Compact and easy to install
Accurate and steady performance with Precision C3 rating
Ideal for all kinds of scale parts and weighing systems
Strong single structure for better stability
Whether you are building a new scale or replacing old parts, the HOLI HL6D single point load cell is a smart and efficient choice.
Product Dimensions(mm):
| Model | Products Description |
| HL6D-3kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-6kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-10kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-15kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-20kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-30kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-40kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| HL6D-50kg-C3 | Aluminium Alloy Steel, C3, 1.5m cable, 4 wires. |
| Qualification |
|
|
| Load Rating | kg | 3/ 6/ 10/ 15/ 20/ 30/ 40/ 50
|
| Precision |
| C3 |
| Maximum Division | Nmax | 3000 |
| Minimum Division | Vmin | Emax/7000 |
| Composition Error | (%FS) | ≤±0.020 |
| Creep Deformation | (%FS/30min) | ≤±0.0167 |
| The influence of temperature on the output sensitivity | (%FS/10℃) | ≤±0.0175 |
| The influence of temperature on the zero output | (%FS/10℃) | ≤±0.020 |
| Rated Output | (MV/V) | 2.0±0.2
|
| Input impedance | (Ω) | 409±6/1065±15 |
| Output impedance | (Ω) | 350±3/1000±10 |
| Insulation Resistance | (MΩ) | ≥5000(50VDC) |
| Zero output | (%FS) | 2 |
| Temperature compensation range | (℃) | -10~+40 |
| Working temperature range | (℃) | -35~+65 |
| Recommend excitation voltage | (V) | 5~12(DC) |
| Maximum excitation voltage | (V) | 18(DC) |
| Safety overload range | (%FS) | 150 |
Limit overloadrange
| (%FS) | 300 |
| Position Error |
| 0.02%/100mm |
