HH8C
HOLI
CE, RoHS
| Quantity: | |
|---|---|
Capacity: 0.5t to 2t
The HH8C load cell from HOLI Scale is a high-precision, shear beam load cell. It is designed for use in various industrial weighing applications, where accuracy and reliability are paramount. Made from durable alloy steel, it offers excellent environmental resistance and long-term stability. The HH8C is available in multiple capacities, making it versatile for
different load requirements.
| Model | Products Description |
| HH8C-500kg-C3 | Alloy steel, Nickel Plated, C3, 3m cable, 4 wires |
HH8C-1000kg-C3 | Alloy steel, Nickel Plated, C3, 3m cable, 4 wires |
| HH8C-1500kg-C3 | Alloy steel, Nickel Plated, C3, 3m cable, 4 wires |
HH8C-2000kg-C3 | Alloy steel, Nickel Plated, C3, 3m cable, 4 wires |
| Qualification | ||
| Load Rating | Kg | 500/1000/1500/2000 |
| Precision | C3 | |
| Maximum Division | nmax | 3000 |
| Minimum Division | Vmin | Emax/10000 |
| Composition Error | %FS | ≤±0.020 |
| Creep Deformation | %FS/30min | ≤±0.0016 |
| The influence of temperature on the output sensitivity | %FS/10℃ | ≤±0.0011 |
| The influence of temperature on the zero output | %FS/10℃ | ≤±0.015 |
| Rated Output | MV/V | 2.0±0.002 |
| Input impedance | Ω | 350±3 |
| Output impedance | Ω | 350±3 |
| Insulation Resistance | MΩ | ≥5000(50VDC) |
| Zero output | %FS | 1.0 |
| Temperature compensation range | ℃ | -10~+40 |
| Working temperature range | ℃ | -35~+65 |
| Recommend excitation voltage | V | 5~12(DC) |
| Maximum excitation voltage | V | 18(DC) |
| Safety overload range | %FS | 120 |
| Limit overloadrange | %FS | 150 |
