Product Description:
Capacity: 0.5t to 5t
The HH8C-SS load cell from HOLI Scale is a high-precision, shear beam load cell. It is designed for use in various industrial weighing applications, where accuracy and reliability are paramount. Made from durable stainless steel, it offers excellent environmental resistance and long-term stability. The HH8C-SS is available in multiple capacities, making it versatile for different load requirements.
Key Features:
Stainless Steel Construction – Durable and ideal for wet or corrosive environments.
Nickel-Plated Finish – Added protection and longevity.
High Accuracy – Built to C3 precision class for dependable, repeatable results.
Compact and Strong – Fits into various weighing solutions and industrial equipment.
Versatile Use – Perfect for platform scales, hopper systems, and more.
Stable and Reliable – Ensures accurate weighing even under rough conditions.
Quality Assured – Engineered by HOLI Scale, trusted in global logistics and industrial sectors.
| Model | Products Description |
HH8C-SS-500kg-C3 | Stainless steel, C3, 3m cable, 4 wires. |
HH8C-SS-1000kg-C3 | Stainless steel, C3, 3m cable, 4 wires. |
HH8C-SS-1500kg-C3 | Stainless steel, C3, 3m cable, 4 wires. |
HH8C-SS-2000kg-C3 | Stainless steel, C3, 3m cable, 4 wires. |
HH8C-SS-3000kg-C3 | Stainless steel, C3, 3m cable, 4 wires. |
HH8C-SS-5000kg-C3 | Stainless steel, C3, 3m cable, 4 wires. |
| Qualification | ||
| Load Rating | Kg | 500/1000/1500/2000/3000/5000 |
| Precision | C3 | |
| Maximum Division | nmax | 3000 |
| Minimum Division | Vmin | Emax/10000 |
| Composition Error | %FS | ≤±0.020 |
| Creep Deformation | %FS/30min | ≤±0.0016 |
| The influence of temperature on the output sensitivity | %FS/10℃ | ≤±0.0011 |
| The influence of temperature on the zero output | %FS/10℃ | ≤±0.015 |
| Rated Output | MV/V | 2.0±0.002 |
| Input impedance | Ω | 350±5 |
| Output impedance | Ω | 350±3 |
| Insulation Resistance | MΩ | ≥5000(50VDC) |
| Zero output | %FS | 1.0 |
| Temperature compensation range | ℃ | -10~+40 |
| Working temperature range | ℃ | -35~+65 |
| Recommend excitation voltage | V | 5~12(DC) |
| Maximum excitation voltage | V | 18(DC) |
| Safety overload range | %FS | 120 |
| Limit overloadrange | %FS | 150 |
