HSB
HOLI
CE
| Quantity: | |
|---|---|
Capacity:3t to 8t
The HSB load cell from HOLI Scale is a high-precision, shear beam load cell. Suitable for platform scale whose capacity is big. Suitable for Axle weighing scale.
| Model | Products Description |
HSB-3000kg-C3 | Alloy steel, C3, 5m cable, 4 wires. |
HSB-8000kg-C3 | Alloy steel, C3, 5m cable, 4 wires. |
| Qualification | |||||
| Load Rating | t | 3/8 | |||
| Precision | C2 | C3 | A5M | B10M | |
| Maximum Division | Nmax | 2000 | 3000 | 5000 | 5000 |
| Minimum Division | Vmin | Emax/5000 | Emax/7500 | Emax/15000 | Emax/10000 |
| Composition Error | %FS) | ≤±0.030 | ≤±0.020 | ≤±0.026 | ≤±0.050 |
| Creep Deformation | %FS/30min | ≤±0.023 | ≤±0.016 | ≤±0.017 | ≤±0.040 |
| The influence of temperature on the output sensitivity | %FS/10℃ | ≤±0.017 | ≤±0.011 | ≤±0.013 | ≤±0.040 |
| The influence of temperature on the zero output | %FS/10℃ | ≤±0.029 | ≤±0.019 | ≤±0.014 | ≤±0.020 |
| Rated Output | MV/V | 2.0±0.020 | |||
| Input impedance | Ω | 350±3.5 | |||
| Output impedance | Ω | 350±2 | |||
| Insulation Resistance | MΩ | ≥5000(50VDC) | |||
| Zero output | %FS | 1.5 | |||
| Temperature compensation range | ℃ | -10~+40 | |||
| Working temperature range | ℃ | -35~+65 | |||
| Recommend excitation voltage | V | 5~12(DC) | |||
| Maximum excitation voltage | V | 18(DC) | |||
| Safety overload range | %FS | 120 | |||
| Limit overloadrange | %FS | 150 | |||
