Model E-Portable

Portable fold open weighbridge

Model E-Portable weighbridge is a modular, surface-mounted system designed for weighing road vehicles up to 80 tons.
Its innovative design incorporates hinges that allow the weighbridge to be transported fully assembled, including all components such as load cells. This feature facilitates rapid installation and easy relocation as needed. With a height of only 30 cm, the E-Portable is ideal for installations where ramp space is limited. The system utilizes high-resolution analog / digital compression load cells, ensuring accurate and reliable measurements. Optional peripheral accessories are available to enhance the weighing system's functionality.

Model:
Model E-Portable
Brand:
Holi
Certificates:
CE

Availability:

Quantity:



Inquiry Contact Now

Product Description

Dimension(m)	Axle Load (t)	Capacity(t)	Deck Plate	Surface Treatment	Specification
3.0×18	up to 10t	up to 80t	Checker	Standard Paint/ Corrosion Protection Paint	Load Cell: Correspondence with all Compression load cell in Analog/ Digital Indicator: Correspondence with all available analog/ digital indicator Wtih Tool Box for Installation Features: * Portable fold open * Easy and quick installation * Transportable * Easy-to-move * Simple and quick maintenance * Surface mounted
3.0×22
3.0×24
Weighbridge dimension and capacity can be customized to suit specific requirements.
