Model A-Standard
Holi
CE
| Quantity: | |
|---|---|
| Dimension(m) | Axle Load (t) | Capacity(t) | Deck Plate | Surface Treatment | Specification |
| 3.0×6.0 | up to 15t | up to 60t | Smooth/ Checker | Standard Paint/ Corrosion Protection Paint/ Sea Defend Epoxy Paint/ Deck Closing Paint | Load Cell:Correspondence with all Double Ended Shear Beam, Compression load cell in Analog/ Digital Indicator: Correspondence with all available analog/ digital indicator With Tool Box for Installation Optional: Guide rail & Ramps Features： * Heavy duty structure * Reliable,durable and accurate * Ideal for various truck types * Pit mounted or surface mounted |
| 3.0×9.0 | |||||
| 3.0×12 | |||||
| 3.0×16 | up to 18t | up to 80t | |||
| 3.0×18 | up to 20t | up to 150t | Smooth/ Checker/ Anti-skidding | ||
| 3.2×18 | |||||
| 3.5×18 | |||||
| 4.0×18 | |||||
| 3.0×22 | |||||
| 3.2×22 | |||||
| 3.5×22 | |||||
| 3.0×24 | |||||
| 3.2×24 | |||||
| 3.5×24 | |||||
| Weighbridge dimension and capacity can be customized to suit specific requirements. | |||||
| Dimension(m) | Axle Load (t) | Capacity(t) | Deck Plate | Surface Treatment | Specification |
| 3.0×6.0 | up to 15t | up to 60t | Smooth/ Checker | Standard Paint/ Corrosion Protection Paint/ Sea Defend Epoxy Paint/ Deck Closing Paint | Load Cell:Correspondence with all Double Ended Shear Beam, Compression load cell in Analog/ Digital Indicator: Correspondence with all available analog/ digital indicator With Tool Box for Installation Optional: Guide rail & Ramps Features： * Heavy duty structure * Reliable,durable and accurate * Ideal for various truck types * Pit mounted or surface mounted |
| 3.0×9.0 | |||||
| 3.0×12 | |||||
| 3.0×16 | up to 18t | up to 80t | |||
| 3.0×18 | up to 20t | up to 150t | Smooth/ Checker/ Anti-skidding | ||
| 3.2×18 | |||||
| 3.5×18 | |||||
| 4.0×18 | |||||
| 3.0×22 | |||||
| 3.2×22 | |||||
| 3.5×22 | |||||
| 3.0×24 | |||||
| 3.2×24 | |||||
| 3.5×24 | |||||
| Weighbridge dimension and capacity can be customized to suit specific requirements. | |||||
