Model E-Modular Lite
Weighbridge
Model E-Modular Lite
Model:Model E-Modular Life
Brand:Holi
Certificates:CE
Request a Quote

Files & Downloads

Share

Product Description

Modular weighbridge with middle empty space

Is a design for middle empty space,  so it is more convenient to clean the dust and mud in the middle. Better reduce the impact on the load cells.


HOLI Model E Modular Lite Weighbridge – Lightweight, Affordable, and Easy to Install

The HOLI Model E Modular Lite is an economic model weighbridge built to deliver reliable results without breaking the bank. Designed with simplicity and practicality in mind, this weighing scale is ideal for businesses that need accurate weight checks but want a more lightweight and cost-friendly option.

Thanks to its easy installation and modular design, the Modular Lite can be set up quickly with less groundwork and labour. Whether you're weighing trucks, goods or materials, this weighing instrument provides the performance you need with lower overall cost and hassle.


Key Features:

  • Economic model with high performance and low cost

  • Simple and easy installation for fast setup

  • Modular structure for flexible layout and portability

  • Durable build for long-term use

  • Suitable for light to medium-duty applications

If you're looking for a smart and affordable weighing solution, the HOLI Modular Lite Weighbridge offers all the essentials — making it a great fit for small businesses, warehouses, and local transport hubs.


Dimension(m)

Axle Load (t)

Capacity(t)Deck PlateSurface TreatmentSpecification
3.0×6.0up to 8t
up to 60t
Smooth/ Checker

Standard Paint/

Corrosion Protection Paint/

Sea Defend Epoxy Paint/

Deck Closing Paint

Load Cell: Correspondence with all Double Ended Shear Beam, Compression load cell in Analog/ Digital


Indicator: Correspondence with all available analog/ digital indicator


With Tool Box for Installation


Optional: Guide rail & Ramps & Middle cover plate


Features:

* Cheaping price

* Modular assembly structure

* Easy installation

* Easy container transport

* Cost savings

* Reliable, durable and accurate

* Pit mounted or surface mounted



3.0×9.0
3.0×12
3.0×16
3.0×18

Smooth/ Checker/

Anti-skidding

3.2×18
3.5×18
4.0×18
3.0×22
3.2×22
3.5×22
3.0×24
3.2×24
3.5×24
Weighbridge dimension and capacity can be customized to suit specific requirements.
