  • HQS

›

HQS
Double Ended Shear Beam Load Cell
HQS
Double Shear Baam Type
Certificates:CE
Request a Quote
Contact Us

Files & Downloads

Share

Product Description

Load Ratingt30
Precision
C3
Maximum DivisionNmax3000
Minimum DivisionVminEmax/10000
Composition Error(%FS)≤±0.020
Creep Deformation(%FS/30min)≤±0.016
The influence of temperature on the output sensitivity(%FS/10℃)≤±0.011
The influence of temperature on the zero output(%FS/10℃)≤±0.015
Rated Output(MV/V)2.0±0.2
Input impedance(Ω)700±7
Output impedance(Ω)700±7
Insulation Resistance(MΩ)≥5000(50VDC)
Zero output(%FS)1.5
Temperature compensation range(℃)-10~+40
Working femperature range(℃)-35~+70
Recommend excitation voltage(V)5~12(DC)
Maximum excitation voltage(V)18(DC)
Safety overload range(%FS)150
Limit overload range
(%FS)300
