AC-LP
Holi
CE
| Quantity: | |
|---|---|
Key Features:
*Ultra -Thin Profile 58mm(2%"): Designed for effortless aircraft positioning without additional ramp requirements.
*Lightweight &Compact Design: Smaller and lighter than conventional aircraft scales, making it easy to transport and deploy.
*Versatile Capacity Options: Available in 5,000kg(10,000kb),10,000kg(20,000Ib),20,000kg(40,000Ib),30,000kg(60,000Ib),and 40,000kg(80,0001b)to accommodate a wide range of aircraft sizes.
*Advanced Load Cell Technology: Fully electronic load cells deliver consistent, stable, and accurate weight measurements.
*Battery-Powered Efficiency: Operates onAA batteries, providing up to 120 hours of continuous use, eliminating the need for external power sources or frequent recharging.
*On-Board Diagnostics: Built-in error detection, temperature compensation, and digital filtering ensure stability and accuracy
in varying conditions.
*Easy-to-Read Display: Equipped with a high-contrast LCD with backlighting, making weight readings clear and visible in any lighting condition.
*Wireless Connectivity Option: Remote monitoring and data transmission available through an optional wireless communication module.
Benefits:
*Wireless Connectivity Option: Remote monitoring and data transmission available through an optional wireless communication module.
*Fast & Efficient Weighing: The ultra-low-profile design allows for quick aircraft positioning, reducing downtime.
Lightweight &Portable-Smaller and lighter than other aircraft scales, making it ideal for frequent use and transport.
*Cost-Effective Operation: Runs on AA batteries, eliminating the need for power cables or frequent recharging.·Minimal Maintenance-Electronic load cells provide stable and repeatable readings with low servicing requirements.
*Versatile Application: Designed for small and medium aircraft, supporting routine maintenance, weight balancing, and safety
compliance checks.
*Reliable Performance in Various Conditions: Integrated temperature compensation and digital filtering ensure high accuracy indifferent environments.
| Specifications | ||||||||||||||||
| Model | AC10-LP | AC20-LP | AC30-LP | AC40-LP | ||||||||||||
| Functional Dimension LxW | 381×381mm (15"×15") | 570×381 mm (2235"x15") | 762×610 mm (30"×24") | 762×610 mm (30"×24") | ||||||||||||
| Outline Dimension | 406×406×43mm (16"×16"x1 %o") | 595×406×50 mm | 788×635×58 mm | 788×635×58 mm | ||||||||||||
| L1xW1xHeight | (236"x16"×2") | (31"×25"×2%" ) | (31"×25"×2% ") | |||||||||||||
| Beveling Dimension L2xW2 | 430×422 mm (16%"×16%") | 520×422 mm (2035"×16%") | 590×651 mm (23%"×25%") | 590×651 mm (23%"×25%") | ||||||||||||
| Weighing Capacity | 5,000kg /10,000kg (10,0001b/20,00001b) | 20,000 kg (40,000 Ib) | 30,000 kg (60,000 Ib) | 40,000 kg (80,000 Ib) | ||||||||||||
| Minimum Division | 5kg/101b | 5kg/101b | 10kg/201b | 10kg/201b | ||||||||||||
| Weighing Accuracy | ±0.1%of reading* | ±0.1%of reading* | ±0.1%of reading* | ±0.1%of reading* | ||||||||||||
| Sensor Quantity | 6pcs | 8pcs | 12pcs | 16pcs | ||||||||||||
| Scale Weight | 18.5kg(37 Ib) | 24.5kg(49Ib) | 45kg(90 Ib) | 52kg(1041b) | ||||||||||||
| Working Temperature | -10~+50℃ | |||||||||||||||
| Working Period | 120 Hours | |||||||||||||||
| Connection | 20m Cable or RFID Wireless Tool Kit | |||||||||||||||
| *Overall performance may be affected by graduation size,capacity,and calibration parameters. | ||||||||||||||||
