HOLI PAW-C Portable Axle Weighing Scale – Lightweight Wheel & Axle Weigher for Dynamic and Static Weighing
The HOLI PAW-C Portable Axle Weighing Scale is a high-performance axle weigher designed for both dynamic and static weighing of vehicles. Compact and easy to transport, it’s ideal for mobile operations where quick and reliable axle weight readings are needed.
This advanced wheel and axle scale features an integrated handle, strong yet lightweight build, and textured rubber ramps to ensure smooth vehicle access. Whether for fleet management, law enforcement, or industrial logistics, the PAW-C offers precise readings while being easy to set up and move.
* Durable aluminium construction.
* Seal protection for normal working environment.
* Load cell based with high Weighing In-Motion accuracy.
* Lightweight aluminium construction with handle for easy transportation.
* Easy-to-use operation, with live weight reading.
* Durability, reliability and repeatable accuracy.
* Rubber ramps for easy truck/tire access.
* Build-in anti-electromagnetic interference to make sure weighing result would not be influenced.
* Extremely simple and reliable connection of the scale to the weight indicator, wired or wireless optional.
The HOLI PAW-C Portable Axle Weighing Scale is the perfect tool for professionals who need a dependable, on-the-go weighing solution. Quick to deploy and easy to operate, it's the ideal choice for safe and accurate vehicle load control wherever you are.
Dynamic Weighing:
Weighs vehicle axles and calculates total weight, gives the axle weight and total weight. Consisting of 2 weighing pads and 1 touch screen indicator with built-in printer.
Static Weighing:
Weighs the whole vehicle and calculates total weight, gives the wheel weight, axle weight and total weight. Consisting of 4, 6 ,8 or even more weighing pads and 1 touch screen indicator with built-in printer.
Weighing Pad Specifications | |||
Functional Area Dimension(mm) | 500(W)×400(L) 19.7"(W)×15.7"(L) | 800(W)×450(L) 31.5"(W)×17.7"(L) | 900(W)×500(L) 35.4"(W)×19.7"(L) |
Overall Dimension(mm) | 500(W)×810(L)×42(H) 19.7"(W)×31.9"(L)×1.7"(H) | 800(W)×1060(L)×42(H) 31.5"(W)×41.7"(L)×1.7"(H) | 900(W)×1110(L)×42(H) 35.4"(W)×43.7"(L)×1.7"(H) |
Rubber Ramp Dimension(mm) | 500(W)×205(L) 19.7"(W)×8.1"(L) | 800(W)×305(L) 31.5"(W)×12"(L) | 900(W)×305(L) 35.4"(W)×12"(L) |
Weighing Capacity | ≤10t(20,000Ib) | ≤15t(30,000lb) | ≤15t(30,000lb) ≤20t(40,000lb) |
| One Weighing Pad Weight | 19kg | 29kg | 33.5kg 43kg |
Two Rubber Ramps Weight | 4.4kg | 19.5kg | 24.8kg 24.8kg |
| Load Cell Quantity | 4pcs | 6pcs | 6pcs 8pcs |
| Overload Protection | 120% | 120% | 120% 120% |
Dynamic Accuracy | ≤±2.5% | ≤±2.5% | ≤±2.5% ≤±2.5% |
| Multi Scales Full Static Accuracy | ≤±0.2% | ≤±0.2% | ≤±0.2% ≤±0.2% |
| Two Scales Axle Static Accuracy | ≤±0.3% | ≤±0.3% | ≤±0.3% ≤±0.3% |
| Sensitive Influence by Temperature | 0.1%/10℃ | 0.1%/10℃ | 0.1%/10℃ 0.1%/10℃ |
| Repeatability | ≤0.01%FS | ≤0.01%FS | ≤0.01%FS ≤0.01%FS |
| Operation Temperature | -10~+65℃ | -10~+65℃ -10~+65℃ | -10~+65℃ -10~+65℃ |
| Wireless Distance | ≤50 Meters | ≤50 Meters | ≤50 Meters ≤50 Meters |
| Working Time | ≤32 Hours | ≤29 Hours | ≤29 Hours ≤26 Hours |
Options | Wired/Wireless | Wired/Wireless | Wired/Wireless Wired/Wireless |
