LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks
Logistic Scale
LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks
Model:LTP
Brand:Holi
Certificates:CE
Request a Quote

Files & Downloads

Share

Product Description

HOLI Scale LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks. This system allows you to weigh your loads directly on the forklift, saving time and improving efficiency in your material handling processes.


LTP is a cost-efficient weighing solution to connect a complete weighing kit to the hydraulic lifting system of forklift truck and use the hydraulic pressure to weigh the load accurately. It includes a weighing indicator, pressure transducer, hydraulic fitting kits and manual.


Key Features

  • Ultra-economical compared with other forklift scales, incredibly low cost with high accuracy.

  • Easy to use, 6-button operation and one-touch weight capture.


Technical Deta

Operating temp

-10~50°℃ ambient.Humidity<90%non-condensing

Storage temp

20~50℃ ambient

IP ratingIndicator:IP65;pressure transducer: IP67
Power supply

7 to 24VDC,0.5Amax

Power fuse1 Aslow blow,20x5mm (located behind rear cover of indicator)
Hydraulic connector

JIC/UNF 9/16-18

Rated pressure5000psi
Outputs

RS-232 printer output. 2 isolated transistor drive outputs(300mA total at 12VDC)

FunctionGross/Tare/ Totalization
