LTP
CE
| Quantity: | |
|---|---|
| Operating temp | -10~50C ambient.Humidity<90% non-condensing. |
| Storage temp | 20~50C ambient. |
| IP rating Indicator | IP65; Pressure transducer:IP67. |
| External materials | ABS,silicon,nylon,acrylic(halogen free), SS304, 17-4PH SS. |
| Power supply | 7 to 24VDC 0.5A max without printer.12VDC only with printer. |
| Power fuse | 1A slow blow, 20x5mm(located behind rear cover of indicator) |
| Hydraulic con | JIC/UNF9/16-18. |
| Rated pressure | 5000psi. |
| Outputs | RS-232 printer output. 2 isolated transistor drive outputs(300mA total at 12VDC) |
Introducing the HOLI Scale LTP Hydraulic Weighing System for Forklifts
The HOLI Scale LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks. This system allows you to weigh your loads directly on the forklift, saving time and improving efficiency in your material handling processes. Here, we provide instructions on how to use the HOLI Scale LTP Hydraulic Weighing System:
Installation: The HOLI Scale LTP Hydraulic Weighing System is easy to install on your forklift or electric pallet truck. Simply connect the hydraulic pressure load cell to the forklift's lifting system, ensuring that it is securely attached and properly aligned. Consult the manufacturer's installation manual for more detailed guidance.
Hydraulic Pressure Load Cell Specifications:
Capacity: Varies depending on the forklift model and lifting capacity
Material: Stainless steel or alloy steel construction for durability
Overload protection: Designed to handle overload situations without damage
Accuracy: Provides high-precision weight measurements, typically within ±1% of the applied load
Temperature range: Operates effectively within a wide range of temperatures
Weight Indicator Specifications:
Display: High-resolution LED or LCD display for easy reading
Power supply: Operates on rechargeable batteries or AC power
Connectivity: RS232 or RS485 communication ports for data transfer
Operating temperature: Designed for use in various temperature conditions
Functions: Tare, zero, accumulation, and other essential weighing functions
Calibration: Before using the HOLI Scale LTP Hydraulic Weighing System for the first time, it is crucial to calibrate it to ensure accurate weight readings. To calibrate the system, follow the manufacturer's instructions, which typically involve lifting a known weight and adjusting the system's settings accordingly.
Weighing: To weigh a load using the HOLI Scale LTP Hydraulic Weighing System, lift the load with your forklift or electric pallet truck as you normally would. The hydraulic pressure load cell will measure the pressure exerted on the lifting system, and the weight indicator will display the corresponding weight of the load.
Tare function: The HOLI Scale LTP Hydraulic Weighing System features a tare function, which allows you to reset the scale to zero before weighing a new load. To use this function, make sure the forklift is empty, and then press the "Tare" button on the weight indicator.
Data management: The HOLI Scale LTP Hydraulic Weighing System is equipped with data management capabilities, allowing you to store and track weight information. Consult the manufacturer's manual for detailed instructions on how to use these features.
Maintenance and troubleshooting: Regularly inspect the hydraulic pressure load cell and weight indicator for signs of wear, damage, or loose connections. Keep the system clean and free of debris to ensure optimal performance. If you encounter any issues, consult the manufacturer's troubleshooting guide or contact their support team for assistance.
By following these instructions, you can make the most of your HOLI Scale LTP Hydraulic Weighing System, enhancing efficiency and accuracy in your material handling processes. This innovative solution is an invaluable asset for businesses seeking to improve their productivity and streamline their operations.
