LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks

Name: LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks
Brand: Holi
Rating: 5.0 (46 reviews)

HOLI Scale LTP Hydraulic Weighing System is an innovative solution designed for efficient and accurate weighing on forklifts and electric pallet trucks. This system allows you to weigh your loads directly on the forklift, saving time and improving efficiency in your material handling processes.

Model:
LTP
Brand:
Holi
Certificates:
CE

Availability:

Quantity:



Inquiry Contact Now

Product Description

LTP is a cost-efficient weighing solution to connect a complete weighing kit to the hydraulic lifting system of forklift truck and use the hydraulic pressure to weigh the load accurately. It includes a weighing indicator, pressure transducer, hydraulic fitting kits and manual.

Key Features

Ultra-economical compared with other forklift scales, incredibly low cost with high accuracy.
Easy to use, 6-button operation and one-touch weight capture.

Technical Deta
Operating temp	-10~50°℃ ambient.Humidity<90%non-condensing
Storage temp	20~50℃ ambient
IP rating	Indicator:IP65;pressure transducer: IP67
Power supply	7 to 24VDC,0.5Amax
Power fuse	1 Aslow blow,20x5mm (located behind rear cover of indicator)
Hydraulic connector	JIC/UNF 9/16-18
Rated pressure	5000psi
Outputs	RS-232 printer output. 2 isolated transistor drive outputs(300mA total at 12VDC)
Function	Gross/Tare/ Totalization
