HSB Shear Beam Load Cell
Shear Beam Load Cell
HSB Shear Beam Load Cell
Shear Beam load cell 3t to 8t
Suitable for platform scale whose capacity is big.
Suitable for Axle weighing scale.
Model:HSB
Brand:HOLI
Certificates:CE
Request a Quote
Contact Us

Files & Downloads

Share

Product Description

Capacity:3t to 8t

The HSB load cell from HOLI Scale is a high-precision, shear beam load cell. Suitable for platform scale whose capacity is big. Suitable for Axle weighing scale.

Product Dimensions(mm)：

HSB Shear Beam Load Cell

Model
Products Description

HSB-3000kg-C3

Alloy steel, C3, 5m cable, 4 wires.

HSB-8000kg-C3

Alloy steel, C3, 5m cable, 4 wires.
Qualification
Load Ratingt3/8
Precision
C2C3A5MB10M
Maximum DivisionNmax2000300050005000
Minimum DivisionVminEmax/5000Emax/7500Emax/15000Emax/10000
Composition Error%FS)≤±0.030≤±0.020≤±0.026≤±0.050
Creep Deformation%FS/30min≤±0.023≤±0.016≤±0.017≤±0.040
The influence of temperature on the output sensitivity%FS/10℃≤±0.017≤±0.011≤±0.013≤±0.040
The influence of temperature on the zero output%FS/10℃≤±0.029≤±0.019≤±0.014≤±0.020
Rated OutputMV/V2.0±0.020
Input impedanceΩ350±3.5
Output impedanceΩ350±2
Insulation ResistanceMΩ

≥5000(50VDC)

Zero output%FS1.5
Temperature compensation range℃-10~+40
Working temperature range℃-35~+65
Recommend excitation voltageV5~12(DC)
Maximum excitation voltageV18(DC)
Safety overload range%FS120
Limit overloadrange
%FS150
