HOLI HL-706 Weighing Controller – Smart Control for Accurate Weighing

The HOLI HL-706 is a high-performance weighing controller and indicator designed for reliable use in industrial weighing systems. Built for speed and accuracy, it connects easily with different weighing instruments, offering a flexible and efficient weighing solution for a variety of applications.

With a compact aluminium case and front panel buttons for easy control, the HL-706 is perfect for panel installation and long-term operation. It provides accurate readings and stable performance, helping to improve your weighing process with minimal effort.

Whether you're managing mixing, filling, or batch processing, this weighing controller supports smooth and consistent results in real time.

Key Features:

• Smart indicator for advanced weighing instruments

• Compact and sturdy aluminium housing for panel mounting

• Clear LED display and easy-to-use keypad

• Ideal for industrial weighing tasks, automation, and batching

• Reliable and precise weighing solution for many applications

Choose the HOLI HL-706 for precise control, long-lasting performance, and a smarter way to manage your weighing scale systems.

Application:

The process control weighing instrument has the characteristics of high speed and high efficiency, complete functions, reliable and stable, which can meet the complex and harsh industrial weighing control needs, and is suitable for many control occasions such as weighing and measuring display, packaging, filling and batching in chemical dangerous occasions with narrow space and difficult wiring.

Specification:

• With the function of 4 single channel meters, saving space.

• Optional 1-4 load cell interfaces, each supporting up to 6 load cells.

• PLC Communication interface option:

  ⁎PROFINET (Dual network port, built-in switch, Siemens PLC).

  ⁎EtherNet/IP(Dual network port, built-in switch, Rockwell PLC, Delta PLC).

  ⁎EtherCAT、MODBUS-TCP(Network port version only).

  ⁎PROFIBUS-DP (Siemens PLC)、CANopen、CC-link(Mitsubishi PLC).

• Multiple calibration modes:

  ⁎Supports up to 3 point weight calibration .

  ⁎Weightless calibration.

  ⁎Remote calibration through PLC communication interface.

• Support applications:

  ⁎Basic weighing version

  ⁎Supports dual speed preset point control and optional 8 simple comparison outputs .

  ⁎Lower/upper limit material level detection.

  ⁎The working power supply supports DC 24VDC±5%, and the maximum power consumption of the entire machine is less than 6w.
