BUFF-C
CE
| Quantity: | |
|---|---|
| Platform Size | Capacity | Specification |
| 0.8x0.8(m) | up to 25000kg | A.Double Decks, smooth top plate or checkered top plate B.Platform material: mild steel C.Shear beam load cell D.With junction box E.With 5m load cell cable |
| 1.0x1.0(m) | ||
| 1.2x1.2(m) | ||
| 1.5x1.5(m) | ||
| Customized | Customized | |
Introduction
The Double Decks Buffering Scale by HOLI Scale represents an innovative solution for weighing heavy steel rolls and other substantial items with enhanced accuracy, stability, and efficiency. This advanced guide will provide an in-depth overview of the Double Decks Buffering Scale's key features, recommendations for successful weighing, and maintenance practices to ensure long-term performance.
Double Decks Buffering Scale: Technical Specifications
The Double Decks Buffering Scale incorporates several essential features designed for accurate and efficient weighing of heavy steel rolls:
a. Bi-level construction: The scale is composed of a base platform for secure grounding and a top platform featuring a V-stop that safely holds and secures heavy steel rolls during weighing.
b. Integrated spring mechanism: The base and top platforms are interconnected via springs, ensuring efficient load distribution and protection for the load cells during the weighing process.
c. High-capacity load cells: The scale is equipped with heavy-duty load cells strategically positioned on the base platform, allowing for precise weight measurements of the steel rolls.
d. Robust build: The scale's construction employs resilient materials capable of withstanding the substantial weight and pressure exerted by heavy steel rolls, ensuring durability and resistance to wear and tear.
e. User-oriented interface: The Double Decks Buffering Scale features an intuitive display and control panel, streamlining operation and providing easy access to weight measurements.
Best Practices for Accurate Weighing
To achieve reliable and consistent results using the Double Decks Buffering Scale, adhere to the following recommendations:
a. Install on a level surface: Position the scale on a flat, stable surface to mitigate inaccuracies and promote stability during weighing operations.
b. Regular calibration: Periodic calibration is crucial to maintaining measurement accuracy. Adhere to the manufacturer's guidelines for calibration procedures.
c. Proper loading and unloading: Employ appropriate equipment and techniques to load and unload steel rolls onto the scale, ensuring accurate positioning and securement within the V-stop.
d. Routine inspection: Consistently examine the scale for indications of wear, damage, or deformation, addressing any concerns promptly to maintain peak performance.
e. Safety adherence: Comply with all safety protocols and precautions during scale operation and heavy steel roll handling to prevent accidents or injuries.
Cleaning and Maintenance for Longevity
To extend the service life of your Double Decks Buffering Scale, adopt the following maintenance and cleaning practices:
a. Maintain cleanliness: Routinely clean the scale, removing any accumulated dirt, debris, or residues that could compromise accuracy.
b. Shield from harsh conditions: When not in use, store the scale in a dry, protected area to prevent damage due to moisture or temperature fluctuations.
c. Load cell inspection and maintenance: Regularly assess the load cells for signs of wear or damage and replace them as necessary to maintain optimal performance.
d. Adherence to manufacturer guidelines: Refer to the user manual specific to your Double Decks Buffering Scale for additional maintenance instructions and recommendations.
Conclusion
HOLI Scale's Double Decks Buffering Scale offers a sophisticated solution for the accurate weighing of heavy steel rolls and other substantial items. By adhering to best practices for weighing, equipment maintenance, and safety protocols, users can optimize their operations and make informed decisions based on precise measurements. Trust the Double Decks Buffering Scale to provide exceptional weighing performance tailored to the demands of heavy steel roll applications.
