* Durable aluminium construction.
* Advanced shock and drop resistant design.
* Low cost, but extreme durability, reliability and repeatable accuracy.
* Good working environment adaptability.
* Load cell deisgn, easy maintenance.
* Lightweight for easy carrying and transport.
* Easy-to-use operation, with live weight reading.
* Built-in digital weight display.
* Backlit display
Weighs the wheels of the vehicle, each wheel with a weighing pad. Consisting of 4, 6, 8 or even more weighing pads.
Weighing Pad Specifications | |||
Functional Area Dimension(mm) | 350(W)×320(L) 13.8"(W)×12.6"(L) | 630(W)×320(L) 24.8"(W)×12.6"(L) | 900(W)×500(L) 31.5"(W)×13.8"(L) |
Overall Dimension(mm) | 450(W)×1106(L)×52(H) 450(W)×1106(L)×56(H) 17.7"(W)×43.5"(L)×2"(H) 17.7"(W)×43.5"(L)×2.2"(H) | 730(W)×1106(L)×52(H) 30(W)×1106(L)×56(H) 28.7"(W)×43.5"(L)×2"(H) 28.7"(W)×43.5"(L)×2.2"(H) | 900(W)×1440(L)×56(H) 35.4"(W)×56.7"(L)×2.2"(H) |
| Rubber Ramp Dimension(mm) | 330(W)×350(L) 13"(W)×13.8"(L) | 590(W)×350(L) 23.2"(W)×13.8"(L) | 800(W)×500(L) 31.5"(W)×19.7"(L) |
Weighing Capacity | ≤6t(12,000Ib) ≤10t(20,000Ib) | ≤18t(15,000lb) ≤15t(30,000lb) | ≤15t(30,000lb) |
One Weighing Pad Weigh | 10.5kg 13.5kg | 17kg 21kg | 26kg |
Two Rubber Ramps Weight | 3.5kg 3.5kg | 6kg 6kg | 16.5kg |
| Load Cell Quantity | 4pcs 6pcs | 6pcs 8pcs | 8pcs |
| Overload Protection | 120% 120% | 120% 120% | 120% |
| Multi Scales Full Static Accuracy | ≤±0.1% ≤±0.1% | ≤±0.1% ≤±0.1% | ≤±0.1% |
| Sensitive Influence by Temperature | 0.1%/10℃ 0.1%/10℃ | 0.1%/10℃ 0.1%/10℃ | 0.1%/10℃ |
| Repeatability | ≤0.01%FS ≤0.01%FS | ≤0.01%FS ≤0.01%FS | ≤0.01%FS |
| Operation Temperature | -10~+80℃ -10~+80℃ | -10~+80℃ -10~+80℃ | -10~+80℃ |
| Wireless Distance | ≤50 Meters ≤50 Meters | ≤50 Meters ≤50 Meters | ≤50 Meters |
| Working Time | ≤31 Hours ≤24Hours | ≤24 Hours ≤20 Hours | ≤20 Hours |
Direct Display | LCD with Backlight,Function:On/Off.TARE.Zero. | ||
