PAW-B-R
Holi
CE, OIML
| Quantity: | |
|---|---|
* Durable aluminium construction.
* Lightweight aluminium construction for easy transportation.
* Low cost,but extreme durability, reliability and repeatable accuracy.
* Built-in ramps for easy truck/tire access.
* Easy-to-use operation, with live weight reading.
* Load cell design, easy maintenance.
* Extremely simple and reliable connection of the scale to the weight indicator, wired or wireless optional
Weighs the whole vehicle and calculates total weight, gives the wheel weight, axle weight and total weight. Consisting of 4, 6, 8 or even more weighing pads and 1 touch screen indicator with built-in printer.
Weighing Pad Specifications | |||
Functional Area Dimension(mm) | 500(W)×400(L) 19.7"(W)×15.7"(L) | 800(W)×450(L) 31.5"(W)×17.7"(L) | 900(W)×500(L) 35.4"(W)×19.7"(L) |
Overall Dimension(mm) | 500(W)×578(L)×54(H) 19.7"(W)×22.8"(L)×2.1"(H) | 800(W)×628(L)×60(H) 800(W)×628(L)×65(H) 31.5"(W)×24.7"(L)×2.4"(H) 31.5"(W)×24.7"(L)×2.6"(H) | 900(W)×678(L)×60(H) 900(W)×678(L)×65(H) 35.4"(W)×26.7"(L)×2.4"(H) 35.4"(W)×26.7"(L)×2.6"(H) |
Weighing Capacity | ≤5t(10,000Ib) | ≤10t(20,000lb) ≤15t(30,000lb) | ≤10t(20,000lb) ≤15t(30,000lb) |
| Load Cell Quantity | 4pcs | 6pcs 8pcs | 6pcs 8pcs |
| Overload Protection | 150% | 150% 150% | 150% 150% |
| Multi Scales Full Static Accuracy | ≤±0.1% | ≤±0.1% ≤±0.1% | ≤±0.1% ≤±0.1% |
| Two Scales Axle Static Accuracy | ≤±0.5% | ≤±0.5% ≤±0.5% | ≤±0.5% ≤±0.5% |
| Sensitive Influence by Temperature | 0.1%/10℃ | 0.1%/10℃ 0.1%/10℃ | 0.1%/10℃ 0.1%/10℃ |
| Operation Temperature | -10~+65℃ | -10~+65℃ -10~+65℃ | -10~+65℃ -10~+65℃ |
| Wireless Distance | ≤50 Meters | ≤50 Meters ≤50 Meters | ≤50 Meters ≤50 Meters |
| Working Time | ≤30 Hours | ≤24 Hours ≤20 Hours | ≤24 Hours ≤20 Hours |
Options | Wired/Wireless | Wired/Wireless Wired/Wireless | Wired/Wireless Wired/Wireless |
