* Durable aluminium construction.
* Lightweight aluminium construction for easy transportation.
* Load cell design, easy maintenance.
* Rubber ramps for easy truck/tire access.
* Easy-to-use operation, with live weight reading.
* Built-in digital weight display.
* Backlit display.
Weighs vehicle axles and calculates total weight, gives the axle weight and total weight. Consisting of 2 weighing pads and 1 touch screen indicator with built-in printer.
Weighs the wheels of the vehicle, each wheel with a weighing pad. Consisting of 2, 4, 6, 8 or even more weighing pads.
Weighing Pad Specifications | |||
Functional Area Dimension(mm) | 500(W)×400(L) 19.7"(W)×15.7"(L) | 800(W)×450(L) 31.5"(W)×17.7"(L) | 900(W)×500(L) 35.4"(W)×19.7"(L) |
Overall Dimension(mm) | 629.5(W)×920(L)×58(H) 24.8"(W)×36.2"(L)×2.3"(H) | 929.5(W)×1170(L)×58(H) 36.6"(W)×46.1"(L)×2.3"(H) | 1029.5(W)×1220(L)×58(H) 40.5"(W)×48"(L)×2.3"(H) |
Rubber Ramp Dimension(mm) | 500(W)×205(L) 19.7"(W)×8.1"(L) | 800(W)×305(L) 31.5"(W)×12"(L) | 900(W)×305(L) 35.4"(W)×12"(L) |
Weighing Capacity | ≤5t(10,000Ib) | ≤10t(20,000lb) ≤15t(30,000lb) | ≤10t(20,000lb) ≤15t(30,000lb) |
| One Weighing Pad Weight | 19kg | 36kg 43kg | 42kg 50kg |
Two Rubber Ramps Weight | 4kg | 17kg 17kg | 20kg 20kg |
| Load Cell Quantity | 4pcs | 6pcs 8pcs | 6pcs 8pcs |
| Overload Protection | 150% | 150% 150% | 150% 150% |
Dynamic Accuracy | ≤±3% | ≤±3% ≤±3% | ≤±3% ≤±3% |
| Multi Scales Full Static Accuracy | ≤±0.1% | ≤±0.1% ≤±0.1% | ≤±0.1% ≤±0.1% |
| Two Scales Axle Static Accuracy | ≤±0.5% | ≤±0.5% ≤±0.5% | ≤±0.5% ≤±0.5% |
| Sensitive Influence by Temperature | 0.1%/10℃ | 0.1%/10℃ 0.1%/10℃ | 0.1%/10℃ 0.1%/10℃ |
| Repeatability | ≤0.01%FS | ≤0.01%FS ≤0.01%FS | ≤0.01%FS ≤0.01%FS |
| Operation Temperature | -10~+65℃ | -10~+65℃ -10~+65℃ | -10~+65℃ -10~+65℃ |
| Wireless Distance | ≤50 Meters | ≤50 Meters ≤50 Meters | ≤50 Meters ≤50 Meters |
| Working Time | ≤45 Hours | ≤43 Hours ≤38 Hours | ≤43 Hours ≤38 Hours |
Direct Display | LCD with Backlight,Function:On/Off.Lb/kg.Zero | ||
