PAW-A
HOLI
CE
| Quantity: | |
|---|---|
* Durable aluminium construction,heavy duty structure.
* Ultra-low profile and integrated design.
* Water-resistant, corrosion proof and shock resistant design.
* Multiple seal protection for tough working environment.
* Lightweight aluminium construction with handle for easy transportation.
* Easy-to-use operation, with live weight reading.
* Durability,reliability and repeatable accuracy.
* Build-in anti-electromagnetic interference to make sure weighing result would not be influenced.
* Extremely simple and reliable connection of the scale to the weight indicator,wired or wireless optional
Weighs vehicle axles and calculates total weight, gives the axle weight and total weight. Consisting of 2 weighing pads and 1 touch screen indicator with built-in printer.
Weighs the whole vehicle and calculates total weight, gives the wheel weight, axle weight and total weight. Consisting of 4, 6, 8 or even more weighing pads and 1 touch screen indicator with built-in printer.
Weighing Pad Specifications | ||
Functional Area Dimension(mm) | 800(W)×430(L) 31.5"(W)×16.9"(L) | 800(W)×550(L) 31.5"(W)×21.6"(L) |
Overall Dimension(mm) | 800(W)×1130(L)×35(H) 31.5"(W)×44.5"(L)×1.4"(H) | 800(W)×1250(L)×45(H) 31.5"(W)×49.2"(L)×1.8"(H) |
Rubber Ramp Dimension(mm) | 800(W)×350(L) 31.5"(W)×13.8"(L) | 800(W)×350(L) 31.5"(W)×13.8"(L) |
Weighing Capacity | ≤15t(30,000Ib) | ≤25t(50,000lb) |
One Weighing Pad Weight | 23kg | 48kg |
| Two Rubber Ramps Weight | 21kg | 21kg |
| Overload Protection | 200% | 200% |
| Load Cell | strain gauge | strain gaug |
Dynamic Accuracy | ≤±3.5% | ≤±3.5% |
| Multi Scales Full Static Accuracy | ≤±0.7% | ≤±0.7% |
| Two Scales Axle Static Accuracy | ≤±1% | ≤±1% |
| Sensitive Influence by Temperature | 0.1%/10℃ | 0.1%/10℃ |
| Repeatability | ≤0.01%FS | ≤0.01%FS |
| Operation Temperature | -10~+65℃ | -10~+65℃ |
| Wireless Distance | ≤30 Meters | ≤30 Meter |
| Working Time | ≤48 Hours | ≤48 Hours |
Options | Wired/Wireless | Wired/Wireless |
