PAW-A-I
CE
| Quantity: | |
|---|---|
* Durable aluminium construction.
* Ultra-low profile and integrated design.
* Water-resistant,corrosion proof and shock resistant design.
* Multiple seal protection for tough working environment.
* Lightweight aluminium construction with handle for easy transportation.
* Easy-to-use operation,with live weight reading.
* Durability, reliability and repeatable accuracy.
* Built-in ramps for easy truck/tire access.
* Built-in digital weight display
* Backlit display.
* Powered by AAA alkaline high capacity batteries.
Weighs the wheels of the vehicle, each wheel with a weighing pad. Consisting of 2, 4, 6, 8 or even more weighing pads.
Weighing Pad Specifications | |
Functional Area Dimension(mm) | 700(W)×430(L) 27.5"(W)×16.9"(L) |
Overall Dimension(mm) | 800(W)×430(L)×30(H) 31.5"(W)×16.9"(L)×1.2"(H) |
Weighing Capacity | ≤10t(20,000Ib) |
One Weighing Pad Weight | 19kg |
| Overload Protection | 200% |
| Load Cell | strain gauge |
| Single Scale Static Accuracy | ≤±1% |
| Sensitive Influence by Temperature | 0.1%/10℃ |
| Repeatability | ≤0.01%FS |
| Operation Temperature | -10~+65℃ |
| Working Time | ≤100 Hours |
Direct Display | LCD with Backlight,Function:On/Off.Lb/kg.Zero. |
